Maytag Washing Machine Cycle [3 Problems, Solutions & Detailed Guide]

If you are having issues with your Maytag washing machine cycle, you’ve come to the right place. This in-depth guide gives you steps on how to fix these issues…

Maytag Washing Machine Rinse Cycle Not Working — How To Fix

If your Maytag washing machine rinse cycle isn’t starting, the following are issues to look for…

1. Water Taps Are Off

If your washing machine isn’t going into the rinse cycle, the first thing you should do is check to ensure that the supply faucets are fully opened. Also ensure that the inlet hoses aren’t bent or kinked in any way, as this could restrict water flow.

2. Clogged Inlet Filters

Your washing machine has water inlet filters at the back. Over time, dirt from your water supply may accumulate in the filters. To clean the filters, you’ll need to disconnect the hoses and pull them out using pliers. For detailed steps on how to do this, read this article: Maytag Washing Machine Filter.

3. Defective Water Inlet Valve

Before concluding that your washer’s water inlet valve is damaged, you should test it. Follow the steps below to do this…

Front Loaders

Take the following steps to test the water inlet valve in your front loader Maytag washing machine…

Step 1. Disconnect your washing machine from the power outlet and turn the water taps off in order to prevent electrocution and water leaks.

Step 2. Disconnect the COLD and HOT water supply hoses from the ports at the back of the machine (make sure to keep a rag nearby in case water spills).

Step 3. Using a Torx-20 screwdriver, take out the nuts holding the top panel to the cabinet. Lift the panel off the washer and set it aside.

Step 4. Use your pliers to release the retaining clamps holding the outlet hoses to the inlet valve assembly. Pull each hose off the inlet valve (some water may spill).

Step 5. Note the positioning of the connectors attached to the inlet valve, then disconnect each one.

Step 6. Use your Torx screwdriver to loosen the bolts holding the inlet valve assembly to the cabinet. Take the inlet valve out of the machine.

Step 7. Get a multimeter, then turn the dial to the lowest setting for ohms of resistance. Place the multimeter’s probes on the inlet valve terminals.

Step 8. For a working valve, look for a reading between 500 and 1500 ohms. If the reading is much lower or higher than these numbers, the valve is damaged and needs to be replaced.

Step 9. If you’ve determined that the inlet valve is in good condition, reinstall it in the cabinet and apply the nuts using your Torx screwdriver.

Step 10. Reconnect the outlet hoses to the appropriate ports on the inlet valve. Use your pliers to slide the retaining clamps into place.

Step 11. Plug each wire connector into its appropriate terminal on the inlet valve. Reconnect the water supply hoses to the ports at the back of the machine.

Step 12. Place the top panel on the cabinet, then apply the screws at the back using your screwdriver.

Step 13. Plug your washing machine into the electrical outlet, then turn the water supply taps back on.

Top Loaders

To test the water inlet valve in your top loader Maytag washing machine, follow the steps below…

Step 1. Make sure to disconnect your washing machine from the outlet and turn the water faucets off before starting this repair in order to prevent electrocution and water leaks.

Step 2. Put some tape over the lid of your washer to help secure it. Insert a putty knife underneath the top panel to release the locking clips. Lift the top panel and support it using a lanyard or by placing it against a wall (do not rely on the hinges for support).

Step 3. Using pliers, release the spring clamps holding the outlet hoses to the ports underneath the top panel. Pull each hose off the top panel (some water may spill out).

See also  How To Install GE Washing Machine… [Detailed Guide]

Step 4. Lower the top panel onto the cabinet. Disconnect the COLD and HOT water supply hoses from the ports at the back of the machine.

Step 5. Loosen the three bolts holding the control panel assembly to the cabinet using a Torx screwdriver.

Step 6. Set the control panel face-down on the cabinet. Note the positioning of the connectors attached to the inlet valve, then disconnect each one.

Step 7. Loosen the nuts holding the inlet valve to the cabinet using a Torx screwdriver. Take the inlet valve off the cabinet.

Step 8. Get a multimeter, then turn the dial to the lowest setting for ohms of resistance. Place the probes of the multimeter on each of the valves terminals.

Step 9. For a working valve, look for a reading between 500 and 1500 ohms. If the reading is much lower or higher than these numbers, the valve is damaged and needs to be replaced.

Step 10. If the valve is in good condition, remount it on the cabinet, then secure by applying the bolts using your Torx screwdriver.

Step 11. Plug each connector into its appropriate terminal on the inlet valve assembly. Lift the control panel and mount it on the cabinet. Secure the control panel by applying the bolts at the back using your Torx screwdriver.

Step 12. Lift the top panel assembly and support it. Reconnect the outlet hoses to the appropriate ports at the bottom of the top panel. Use your pliers to slide the retaining clamps into place.

Step 13. Snap the top panel onto the cabinet, then peel the tape off the lid. Reconnect the water supply hoses to their corresponding ports on the cabinet. Plug your washer into the outlet and turn the water taps on.

Check out these other articles…

Maytag Washing Machine Error Codes [Proven Solutions]

Maytag Washing Machine Filter [Problems, Solutions & Guide]

How To Clean Maytag Washing Machine [Detailed Guide]

Maytag Washing Machine Smells [Proven Solutions]

Maytag Washing Machine Motor [Issues & Solutions]

Maytag Washing Machine Is Leaking [How To Fix]

Maytag Washing Machine Shakes Violently [Causes & Solutions]

Maytag Washing Machine Drain Cycle Not Working — How To Fix

If this Maytag washing machine cycle isn’t working, the following are issues to look for…

1. Clogged Pump Filter

If you have a front loader, it is advised that you check the pump filter regularly to ensure that it isn’t clogged. For detailed steps on how to clean the pump filter, read this article: Maytag Washing Machine Filter.

2. Damaged Pump

Another thing that could prevent your Maytag washing machine from draining is a damaged pump. Before rushing to replace this part, it is advised that you test it first using a multimeter. Here’s how to do this…

Front Loaders

To test the drain pump assembly in your front loader Maytag washing machine, follow the steps below…

Step 1. In order to prevent electrocution, it is advised that you disconnect your washer from the outlet before starting this repair.

Step 2. Using a Torx screwdriver, loosen the nuts holding the lower access panel to the front of the cabinet. Pry the panel off the washer and set it aside.

Step 3. Place a container underneath the pump filter. Turn the filter knob and pull it out. Once all the water has drained out into the container, put the filter back in.

Step 4. Pry the cap off the drain pump and disconnect the wire harness from the terminal. Use pliers to release the spring clamps holding the sump hose and outlet hose to the pump.

Step 5. Disconnect each of the hoses from the drain pump (make sure to keep a rag nearby). Loosen the bolts holding the pump assembly to the cabinet using a 1/4 inch nut-driver. Pull the drain pump out of the cabinet.

Step 6. Get a multimeter and turn the dial to the ohms setting. Place the probes of the multimeter on the drain pump terminals. For a working pump, you should get a reading of roughly 16 ohms.

Step 7. If the reading is much lower or higher than this number, the pump is damaged and needs to be replaced. If the pump is in good condition, reinstall it in the cabinet and apply the bolts using your 5/16 inch nut-driver.

See also  Bosch Washing Machine Pump [Problems & Solutions]

Step 8. Plug the wire connector back into the pump assembly, then snap the cap on. Reconnect each of the outlet hoses to the ports on the drain pump, then use pliers to move the retaining clamps into place.

Step 9. Snap the lower front access panel onto the machine, then apply the nuts using your Torx screwdriver. Plug your washing machine back into the electrical outlet.

Top Loaders

Follow the steps below to test the drain pump assembly in your top loader Maytag washing machine with the following steps…

Step 1. Turn your washer’s water supply taps off and disconnect the power cord from the outlet in order to prevent electrocution and water leakage.

Step 2. Use a pair of pliers to release the retaining clamp holding the drain hose to the port at the back of the machine. Detach the hose from the cabinet

Step 3. Spread a towel underneath the water inlet hoses at the back of the machine to catch any leaks. Disconnect the water inlet hoses from the ports.

Step 4. Put some tape on the lid of your washing machine to secure it. Tip the appliance backwards carefully, then set it on the floor.

Step 5. Pry the cap off the drain pump, then unplug the wire connector. Use pliers to squeeze the retaining clamps holding outlet hoses to the pump, then slide them out of place.

Step 6. Pull each hose off the drain pump (some water may spill out, so keep a rag nearby). Loosen the bolts holding the pump assembly to the bottom of the tub using a 5/16 inch nut-driver.

Step 7. Detach the drain pump from the cabinet. Get a multimeter and turn the dial to the ohms setting. Place the probes of the meter on the pump terminals. For a reading of roughly 16 ohms.

Step 8. If the reading is much higher or lower than this number, the pump is damaged and needs to be replaced.

Step 9. If you’ve determined that the pump is in good condition, remount it at the bottom of the tub, then apply the bolts using your 5/16 inch nut-driver.

Step 10. Plug the wire connector back into the drain pump. Reconnect the outlet hoses to the ports on the pump, then use your pliers to move the retaining clamps into place.

Step 11. Carefully lift your washing machine onto its feet and peel the tape off the lid. Reconnect the drain hose to the port at the back of the machine, then use pliers to slide the retaining clamp into place.

Step 12. Reconnect the COLD and HOT water supply hoses to their corresponding ports at the back of the machine. Turn the water taps on, then plug the power cord back into the outlet.

3. Damaged Pump Impeller

The impeller is mounted inside the pump assembly. The impeller blades help push the water through the pump. If these blades get damaged, your washing machine will not be able to drain water. Here’s how to inspect this part…

Front Loaders

Inspect the impeller in your front loader Maytag washing machine drain pump with the following steps…

Step 1. Make sure to disconnect your washing machine from the outlet before starting this procedure in order to prevent electrocution.

Step 2. Take out the screws holding the lower front access panel to the cabinet using a Torx screwdriver. Lift the panel off the machine and set it aside.

Step 3. Place some towels on the floor underneath the pump filter knob. Turn the filter knob and take it out (some water will spill out).

Step 4. Once all the water has drained out, use your pliers to release the spring clamps holding the sump hose and outlet hoses to the pump. Disconnect each hose from the drain pump.

Step 5. Pry the cap off the pump and disconnect the wire harness. Loosen the bolts holding the drain pump to the cabinet. Pull the pump assembly out of the cabinet.

Step 6. Insert a flat-blade screwdriver into the lint filter opening. Try using the screwdriver to rotate the impeller blades. If the blades don’t turn or are broken, you’ll need to replace the entire pump.

See also  How To Replace Tub Bearing On Amana Washer [Detailed Guide]

Step 7. If the impeller blades are in good condition, reinstall the pump in the cabinet, then apply the nuts using your screwdriver.

Step 8. Reconnect the wire harness to the drain pump. Connect the sump hose and outlet hose to the ports on the pump, then move the retaining clamps into place using pliers.

Step 9. Snap the lower access panel back onto the cabinet, then apply the screws using your Torx screwdriver. Reconnect your washing machine to the power outlet.

Top Loaders

To check the pump impeller in your top loader Maytag washing machine, follow the steps below…

Step 1. Turn your washer’s water supply taps off and disconnect the power cord from the outlet before starting this repair in order to prevent electrocution and water leaks.

Step 2. Using a pair of pliers, release the retaining clamp holding the main outlet hose to the back of the cabinet. Disconnect the hose from the machine.

Step 3. Place some tape on the lid of your washer to help secure it. Loosen the HOT and COLD water inlet hoses attached to the back of the machine.

Step 4. With someone assisting you, tip your washing machine backwards carefully and set it on the floor.

Step 5. Use pliers to release the clamps holding the outlet hoses attached the pump. Disconnect each hose from the pump (some water may spill).

Step 6. Pry the cap off the drain pump, then disconnect the wire harness. Take out the bolts holding the pump to the bottom of the outer tub.

Step 7. Detach the pump from the tub. Insert a flat-blade screwdriver into the pump opening closest to the pump motor. Try using the screwdriver to rotate the impeller blades.

Step 8. If you notice that the blades are broken or don’t turn, you’ll need to replace the entire drain pump.

Step 9. If the impeller is in good condition, remount the pump at the bottom of the tub, then tighten the screws using your nut-driver.

Step 10. Plug the wire harness back into the drain pump. Reconnect the outlet hoses to their corresponding ports on the pump, then secure them with the retaining clamps.

Step 11. Carefully lift the washing machine onto its feet, then peel the tape off the lid. Connect the main drain hose back to the port on the machine, then secure it using the retaining clamp.

Step 12. Reconnect the COLD and HOT water supply hoses to their corresponding ports, Turn the water taps on and reconnect the power cord to the outlet.

Maytag Washing Machine Cycle Not Changing — Solved

If your Maytag washing machine cycles don’t change, it indicates an issue with the shift actuator, before concluding that the part is damaged, you should check to ensure that the connector is properly attached. Here’s how to do this…

Step 1. Disconnect your washing machine from the outlet and turn the water faucets off before starting this repair in order to prevent leaks and electrocution.

Step 2. Spread a towel on the floor underneath the water supply hoses to catch any leaks. Disconnect the water supply hoses from the ports at the back of the washer.

Step 3. Use pliers to release the retaining clamp holding the drain hose to the port a the washer. Detach the hose from the cabinet.

Step 4. Place some tape on the lid of your washer to help secure it. With someone helping you if needed, tip your washing machine backwards carefully and set it on the floor.

Step 5. Use a 5/16 inch nut-driver to loosen the screws holding the belt guard to the bottom of the tub. Take the guard off and set it aside.

Step 6. Inspect the wire connector attached to the shift actuator at the bottom of the tub and ensure it is properly connected.

Step 7. Put the belt guard back in place and apply the nuts using a 5/16 inch nut-driver. Carefully lift the washing machine back onto its feet and peel the tape off the lid.

Step 8. Reconnect the drain hose to the port at the back of the cabinet, then use your pliers to slide the retaining clamp into place.

Step 9. Reconnect the COLD and HOT water supply hoses to the ports at the back of the machine.

Step 10. Turn the water taps on, then plug the power cord back into the outlet. To see if the issue has been fixed, try running a wash cycle.

Note: For steps on how to further test your washer’s shift actuator, read this article: Maytag Washing Machine Actuator.
