If your Maytag washing machine is not spinning, don’t worry. In this in-depth guide, we’ll be explaining the causes of this issue providing steps on how to deal with them…
Table of Contents
Maytag Washing Machine Is Not Spinning — Solved
If your Maytag washing machine is not spinning, the following are issue to look for…
1. Damaged Transmission Assembly (Top Loaders)
To replace a damaged transmission assembly in your top loader Maytag washing machine, follow the steps below…
Step 1. Before starting this repair, it is advised that you disconnect your machine from the electrical outlet and turn the water taps off.
Step 2. Place some tape on the lid of your washing machine to help secure it. Go to the back of your washer, then use pliers to disconnect the water supply hoses (keep a rag nearby in case water spills).
Step 3. With a 1/4 inch nut-driver, take out the nut at the back of the machine holding the wiring and tube guard. Take the panel off and set it aside.
Step 4. Use your nut-driver to loosen the screws holding the top panel to the cabinet. Carefully lift the top panel assembly, then support it against a wall or using a lanyard.
Step 5. Use a flat-blade screwdriver to help pry the cap off the agitator. Pry the tub cover off the tub assembly.
Step 6. Pull the lint filter out of the agitator. Loosen the bolt holding the agitator to the inner tub using a 7/16 inch socket wrench. Carefully lift the agitator out of the tub and set it aside.
Step 7. Using a hammer and a tub nut wrench, loosen the bolt holding the inner tub to the transmission shaft. Carefully lift the inner tub out of the cabinet and set it aside.
Step 8. Use your hammer to carefully knock the drive block off the transmission shaft. Lower the top panel back onto the cabinet, then use your 1/4 inch nut-driver to apply the screws.
Step 9. Pull your washing machine’s drain hose out of the home drain. Tip your washing machine forwards carefully and set it on the floor (if needed, get someone to help you).
Step 10. With a 5/16 inch nut-driver, take out the nuts holding the belt guard to the bottom of the machine. Take the belt guard off and set it aside.
Step 11. Take the drive belt off the motor pulley and transmission pulley. Disconnect the wire harness attached to the motor assembly.
Step 12. Loosen the bolts holding the drive motor to the transmission plate using a 10mm socket wrench. Carefully lift the motor off the plate and set it aside.
Step 13. Loosen the nut securing the shift actuator to the transmission assembly using your 1/4 inch nut-driver. Disconnect the wire harness attached to the actuator, then set it aside.
Step 14. Unplug the capacitor wire connector. Take out the bolts holding the capacitor to the plate using your nut-driver. Set the capacitor aside.
Step 15. With a 13mm socket, take out the bolt holding the pulley wheel to the transmission shaft. Take the pulley wheel off and set it aside.
Step 16. Pry the splutch housing off the shaft. Pull the basket drive gear and spring off the transmission shaft, then set them aside.
Step 17. Loosen the bolts holding the transmission assembly to the bottom of the outer tub using a 7/16 inch socket wrench. Carefully pull the transmission assembly out of the tub, then set it aside.
Step 18. Pull the old tub seal out of the opening at the bottom of the tub. Take your new washing machine transmission assembly out of its packaging.
Step 19. Mount the new transmission assembly on the outer tub, then secure it by applying the bolts with your 7/16 inch socket wrench.
Step 20. Place the spring and basket drive gear on the new transmission shaft. Snap the splutch housing onto the shaft.
Step 21. Place the pulley wheel on the shaft, then apply the 13mm bolt to secure it. Mount the capacitor and shift actuator on the transmission plate, then secure them by applying the screws with your 1/4 inch nut-driver.
Step 22. Plug the wire connectors back into the shift actuator and capacitor. Mount the drive motor on the transmission plate. Secure the motor by applying the bolt using your socket wrench.
Step 23. Plug the wire harness into the drive motor assembly. Loop the drive belt around the motor pulley and transmission pulley (ensure that the belt is turned with the grooved part facing inwards).
Step 24. Put the belt guard on the transmission assembly. Secure the guard by applying the 5/16 inch bolts.
Step 25. Carefully lift your washing machine onto its feet. Go to the back of the machine, then loosen the bolts holding the top panel using your 1/4 inch nut-driver.
Step 26. Lift the top panel and support it. Slide the drive block onto the new transmission shaft.
Step 27. Lower the inner tub onto the shaft. Secure the inner tub assembly by applying the tub nut.
Step 28. Place the agitator on the transmission shaft. Secure the agitator by applying the bolts using your 7/16 inch socket wrench.
Step 29. Put the lint filter back in the agitator, then snap the cap on. Snap the tub cover onto the assembly.
Step 30. Lower the top panel onto the cabinet, then apply the bolts at the back using your 1/4 inch nut-driver. Put the wiring and tube guard back in place, then apply the nut.
Step 31. Reinsert your washer’s drain hose into the standpipe. Reconnect the COLD and HOT water supply hoses to their corresponding ports at the back of the machine.
Step 32. Peel the tape off your washer’s lid. Turn the water supply taps back on, then plug the power cord into the electrical outlet. To ensure that the issue has been fixed, try running a wash cycle.
Check out these other articles…
Maytag Washing Machine Error Codes [Proven Solutions]
How To Clean Maytag Washing Machine [Detailed Guide]
Maytag Washing Machine Smells [Proven Solutions]
Maytag Washing Machine Motor [Issues & Solutions]
Maytag Washing Machine Is Leaking [How To Fix]
Maytag Washing Machine Shakes Violently [Causes & Solutions]
Maytag Washing Machine Cycle [Detailed Guide, Problems & Solutions]
2. Damaged Drum Rollers (Dryers)
If your Maytag dryer isn’t spinning, it could be that the drum rollers have gone bad. Follow the steps below to replace this part…
Step 1. In order to prevent any chances of electrocution, it is advised that you disconnect your washer from the outlet before starting this repair.
Step 2. Loosen the bolts holding the lower access panel to the cabinet using a 5/16 inch nut-driver. Lift the panel off the machine and set it aside.
Step 3. Take out the bolts at the bottom of the main front panel. Lift the panel off the machine. Disconnect the door switch wires attached to the panel, then set the panel aside.
Step 4. With your nut-driver, loosen the bolts holding the top panel to the cabinet. Lift the panel and support it using a lanyard, or by placing it against a wall.
Step 5. Unplug the light assembly wires at the front of the drum. Loosen the bolts holding the front bulkhead to the cabinet. Lift the bulkhead off the drum and set it aside.
Step 6. Reach under the drum carefully, then take the drive belt off the idler pulley and motor pulley. Lift the belt and drum out of the cabinet, then set them aside.
Step 7. Using needle-nosed pliers, carefully take the snap ring off the drum roller you want to replace. Slide the washer nut and roller off the shaft, then discard them.
Step 8. Take your roller out of its packaging. Slide the new roller and washer onto the axle. Secure the new roller by putting the snap ring in place.
Step 9. Carefully guide the belt and drum into the cabinet. Reach underneath the drum, then loop the belt around the motor pulley and idler pulley in a zig-zag formation.
Step 10. Mount the front bulkhead on the cabinet, then tighten the screws using your 5/16 inch nut-driver.
Step 11. Plug the light assembly wires back in. Lower the top panel and snap it onto the cabinet. Secure the top panel by applying the screws at the front.
Step 12. Plug the wires back into the door switch on the front panel. Mount the front panel on the cabinet, then use your nut-driver to apply the nuts.
Step 13. Place the lower front access panel on the cabinet, then apply the screws. Plug your washing machine back into the electrical outlet, then ensure that the issue has been fixed by running a cycle.
3. Damaged Drum Support Glide (Dryers)
To replace a damaged drum support glide in your Maytag dryer, follow the steps below…
Step 1. Ensure that your machine is disconnect from the outlet before starting this repair, in order to prevent electrocution.
Step 2. Loosen the screws at the bottom of the front panel. Lift the panel off the cabinet. Disconnect the wires connected to the door switch on the front panel. Set the panel.
Step 3. Pull the the door switch wires out of the retainer on the front bulkhead. Loosen the bolts holding the bulkhead to the cabinet using your nut-driver. Lift the bulkhead off and set it aside.
Step 4. Get a drill with a 1/8 inch drill bit. Drill through the drum glide rivets on the front bulkhead. Take the old glide off the bulkhead and discard it.
Step 5. Take your new drum glide out of its packaging. Insert the tabs of the new glide into the slots on the bulkhead rim. Use a rivet gun to apply the provided rivets to the glide.
Step 6. Remount the front bulkhead on the cabinet, then use your 5/16 inch nut-driver to apply the bolts.
Step 7. Secure the door switch wires in the retainer on the bulkhead. Plug the door switch wires back into the front panel. Mount the front panel on the cabinet, then use your screwdriver to apply the bolts at the bottom.
Step 8. Plug your machine back into the power outlet, then try running a cycle to ensure that everything works properly.
4. Damaged Drive Pulley
If the drive pulley in your washer gets damaged, your machine will not be able to spin. To replace a damaged pulley wheel in your Maytag washing machine, follow the steps below…
Top Loaders
Take the following steps to replace the transmission pulley in your top loader Maytag washing machine…
Step 1. Prevent electrocution and water leakage by turning your washers water taps off and disconnecting the power cord from the outlet before starting this repair.
Step 2. Go to the back of your washer, then use a pair of pliers to release the retaining clamp holding the drain hose to the port on the cabinet. Disconnect the hose from the port.
Step 3. Place some tape on your washing machine’s lid to secure it. Disconnect each of the water supply hoses from the ports at the back of the cabinet (some water may spill out, so keep a rag nearby).
Step 4. Carefully tip your washer backwards and set it on the floor (get someone to help you if needed).
Step 5. Loosen the bolts holding the belt guard to the bottom of the machine using a 5/16 inch nut-driver. Take the belt guard off and set it aside.
Step 6. Unhook the drive belt from the motor pulley and transmission pulley, then set it aside. Loosen the bolt holding the transmission pulley to the shaft. Take the pulley off and discard it.
Step 7. Prepare your new washing machine pulley wheel for installation by taking it out of its packaging. Place the new pulley on the shaft, then secure it by applying the 13mm bolt.
Step 8. With the grooved side turned inwards, loop the drive belt around the two pulleys. Put the belt guard back on, then tighten then nuts using your 5/16 inch nut-driver.
Step 9. Carefully lift your washer back onto its feet and peel the tape off the lid. Reconnect the drain hose to the port at the back of the machine, then move the retaining clamp into place.
Step 10. Reconnect the water supply hoses to the ports at the back of the machine (ensure that the hoses are secured properly in order to prevent water leaks).
Step 11. Plug your machine back into the electrical outlet, then turn the water taps on. To ensure that the issue has been fixed, try running a spin cycle.
Front Loaders
To replace the drive pulley in your front loader Maytag washing machine, follow the steps below…
Step 1. Disconnect your appliance from the outlet in order to prevent any chances of electrocution.
Step 2. Using a 1/4 inch nut-driver, take out the bolts holding the rear panel to the cabinet. Carefully lift the panel off the machine and set it aside.
Step 3. Take the drive belt off the two pulleys and set it aside. Jam the pulley using arm of a hammer.
Step 4. Loosen the bolt holding the drive pulley to the back of the tub using a 24mm socket wrench. Take the pulley off the shaft and set it aside.
Step 5. Take your new drive pulley out of its packaging and mount it on the inner tub shaft. Secure the new pulley by applying the bolt with your 24mm socket wrench.
Step 6. Loop the drive belt around the pulleys. Mount the rear access panel on the cabinet. Secure the panel by applying the screws with your 1/4 inch nut-driver.
Step 7. Plug your washing machine’s power cord back into the outlet, then ensure that everything works properly by running a spin cycle.
5. Damaged Rotor
Follow the steps below to replace the rotor in your Maytag washing machine…
Top Loaders
To replace the rotor assembly in your Maytag top loader washing machine, follow the steps below…
Step 1. In order to prevent water leaks and electrocution, make sure to disconnect your washer from the outlet and turn the water taps off before starting this repair.
Step 2. Use pliers to disconnect the water supply hoses from the ports at the back of the machine (some water may spill out, so keep a rag nearby).
Step 3. Place some tape on the lid of your washing machine to secure it. Pull the drain hose out of the home drain.
Step 4. Tip your machine forwards a bit and set it on the floor. Loosen the bolt holding the rotor to the bottom of the tub using a 1/4 inch Allen wrench.
Step 5. Carefully pry the rotor off the tub and set it aside. Take your new rotor assembly out of its packaging. Mount the new rotor on the tub, then secure it by applying the nut with your 1/4 inch Allen wrench.
Step 6. Carefully lift the machine back onto its feet and peel the tape off the lid. Reinsert the drain hose into the home drain.
Step 7. Reconnect the water supply lines to the ports at the back of the cabinet. Plug your washing machine into the electrical outlet, then turn the water taps on. To ensure that the issue has been fixed, try running a spin cycle.
Front Loaders
To replace the rotor assembly in your front loader Maytag washing machine, take the steps below…
Step 1. In order to prevent electrocution, it is advised that you disconnect your washing machine from the outlet before starting this repair.
Step 2. Use a 1/4 nut-driver, loosen the bolts holding the rear panel to the cabinet. Lift the panel off the washer and set it aside.
Step 3. Using an 11/16 inch socket wrench, loosen the bolt holding the rotor assembly to the back of the tub. Pry the rotor off the tub and set it aside.
Step 4. Take your new washing machine rotor out of its packaging. Mount the new rotor on the stator at the back of the tub, then secure it by applying the bolt with your 11/16 inch socket wrench.
Step 5. Place the rear panel on the cabinet, then apply the nuts using your 1/4 inch nut-driver. Plug your washing machine into the electrical outlet, then try running a spin cycle to ensure that everything works properly.
6. Damaged Drum Roller Axle (Dryers)
To replace the drum roller axle in your Maytag dryer, follow the steps below…
Step 1. Prevent any chances of electrocution by disconnecting your washer from the outlet before starting this repair.
Step 2. With a 5/16 inch nut-driver, loosen the bolts holding the lower front access panel to the cabinet. Lift the panel off the machine and set it aside.
Step 3. Take out the bolts under the main front panel. Lift the main front panel off the cabinet. Disconnect the door switch wires attached to the front panel, then set the panel aside.
Step 4. Use your nut-driver to loosen the nuts holding the top panel to the cabinet. Lift the top panel and support it.
Step 5. Disconnect the light assembly wires from the front bulkhead, then release the wires from the retainer.
Step 6. With your 5/16 inch nut-driver, take out the screws securing the bulkhead to the cabinet. Carefully lift the bulkhead off the machine and set it aside.
Step 7. Reach underneath the drum carefully, then unhook the drive belt from the motor and idler pulleys. Lift the belt and drum out of the cabinet and set it aside.
Step 8. Using needle-nosed pliers or a flat-blade screwdriver, take off the snap ring securing the roller to the support axle. Slid the drum roller off the axle and set it aside.
Step 9. With your 5/16 inch nut-driver, loosen the bolts holding the support axle to the rear of the machine. Take the axle off and discard it.
Step 10. Prepare your new drum roller axle for installation by taking it out of its packaging. Mount the axle on the cabinet, then secure it by applying the bolts with your nut-driver.
Step 11. Slide the roller onto the new axle. Secure the roller by snapping the retaining ring on.
Step 12. Carefully lift the belt and drum, then guide them into the cabinet. Reach underneath the drum, then loop the drive belt around the motor pulley and idler pulley in a zig-zag formation.
Step 13. Remount the front bulkhead on the cabinet. Secure the bulkhead by applying the bolts with your 5/16 inch nut-driver.
Step 14. Plug the light assembly wires back in, then secure them in the retainers on the bulkhead.
Step 15. Lower the top panel onto the cabinet, then apply the screws using your nut-driver. Plug the door switch wires back into the main front panel.
Step 16. Mount the main front panel on the cabinet, then use your 5/16 inch nut-driver to apply the bolts at the bottom.
Step 17. Snap the lower access panel onto the cabinet, then apply the bolts at the bottom. Plug your dryer back into the outlet, then try running a cycle to ensure that the issue has been fixed.
7. Damaged Drive Belt
The drive belt is looped around the motor pulley and drive pulley. If this belt wears out or gets damaged, your machine will not be able to spin. For detailed steps on how to replace this part, read this article: Maytag Washing Machine Belt.
8. Damaged Bearings
The bearings are mounted in the outer tub. If the bearings get warped or damaged, your drum will not be able to spin. For detailed steps on how to replace this part, read this article: Maytag Washing Machine Bearings.
