Maytag Washing Machine Will Not Start [How To Fix]

If your Maytag washing machine will not start, don’t worry; you’ve come to the right place. This detailed guide lists the causes of this issue and gives you steps on how to deal with them…

Maytag Washing Machine Will Not Start — Solution

If your Maytag washing machine will not start, look for the following issues…

1. Damaged Capacitor (Top Loaders)

To replace a damaged capacitor in your top loader Maytag washing machine, follow the steps below…

Step 1. Turn your washing machine’s water supply taps off and disconnect the appliance from the power outlet in order to avoid electrocution and leakage.

Step 2. Secure the lid of your washing machine by putting some tape on it. Disconnect the two water supply hoses from the ports at the back of the cabinet (we recommend keeping a rag nearby to clean any leaks).

Step 3. Use your pliers to release the spring clamp holding the main drain hose to the back of the cabinet. Detach the hose from the machine and set it aside.

Step 4. Get someone to help you tip the machine backwards carefully and set it on the floor.

Step 5. Loosen the bolts holding the belt guard to then bottom of the tub using a 5/16 inch nut-driver. Take the belt guard off and set it aside.

Step 6. Detach the wire harness connected to the capacitor on the transmission plate. Use a 1/4 inch nut-driver to loosen the screw holding the capacitor to the plate. Take the capacitor off and discard it.

Step 7. Prepare the new start capacitor for installation by taking it out of its packaging. Mount the capacitor on the plate, then secure it by applying the screw with your 1/4 inch nut-driver.

Step 8. Put the belt guard back on. Secure the guard by applying the screws with your 5/16 inch nut-driver.

Step 9. With someone helping you, lift your washing machine back onto its feet. Peel the tape off the lid of your washer.

Step 10. Reattach the two water supply hoses to their corresponding ports at the back of the machine.

Step 11. Attach the main drain hose to the port at the back of the cabinet. Secure the hose by sliding the retaining clamp into place using pliers.

Step 12. Plug your washing machine back into the electrical outlet and turn the water taps on. Try turning your machine on to see if the issue has been fixed.

2. Damaged Power Cord

Another thing that could prevent your washing machine from starting is a damaged power cord. Follow the steps below to replace the power cord in your Maytag washing machine…

Front Loaders

Take the following steps to replace a damaged power cord in your Maytag front loader washing machine…

Step 1. Disconnect the power cord from the outlet before starting this procedure in order to prevent electrocution.

Step 2. Loosen the bolts holding the top panel to the cabinet using a Torx-20 screwdriver. Lift the panel off the machine and set it aside.

Step 3. Reach into the cabinet and disconnect the power cord connectors from the line filter. Loosen the bolt holding the grounding wire to the back of the cabinet using a 1/4 inch nut-driver.

Step 4. Use pliers to rotate the power cord strain relief. Pull the power cord connectors out of the cabinet. Discard the old cord.

Step 5. Take your new washing machine power cord out of its packaging. Pass the connectors of the new power cord through the opening at the back of the cabinet.

See also  Whirlpool Washing Machine Agitator [How To, Issues & Solutions]

Step 6. Plug the connectors into the appropriate terminals on the line filter. Place the grounding wire on the cabinet, then secure it by applying the bolt with your 1/4 inch nut-driver.

Step 7. Remount the top panel on the cabinet, then apply the bolts at the back to secure it.

Step 8. Plug the new power cord into the outlet, then try turning it on to see if the issue has been fixed.

Top Loaders

Follow the steps below to replace a damaged power cord in your top loader Maytag washing machine…

Step 1. Turn your washer’s water supply taps off, then disconnect the power cord from the outlet before starting this fix.

Step 2. Using pliers if needed, disconnect the water inlet hoses from the ports at the back of the machine (some water may spill out, so we recommend keeping a rag nearby).

Step 3. Use a 1/4 inch nut-driver to take out the screws at the back of the cabinet holding the control panel. Pry the panel off the cabinet, then disconnect the wire from the main control board.

Step 4. Loosen the bolts holding the upper rear panel using your 1/4 inch nut-driver. Slide the panel off the cabinet and set it aside.

Step 5. Disconnect the power cord’s wires from the main control board and the noise filter. Loosen the bolt holding the power cord’s grounding wire using a 1/4 inch nut-driver.

Step 6. Loosen the bolts holding the wiring and tube guard to the back of the cabinet. Take the guard off and set it aside.

Step 7. Take out the bolts holding the top panel assembly using your 1/4 inch nut-driver. Carefully lift the top panel and support it using a lanyard.

Step 8. Using needle-nosed pliers, release the power cord retainer from the bottom of the top panel. Lower the top panel and snap it onto the cabinet.

Step 9. Discard the old power cord, then take the new one out of its packaging. Put the wiring and tube guard back in place, then secure it by applying the bolts with your nut-driver.

Step 10. Reapply the screws to secure the top panel to the cabinet. Snap the power cord retainer into the slot on the top panel.

Step 11. Plug the power cord wires to the main control board and the line filter. Put the grounding wire in place on the cabinet, then apply the screw using your nut-driver.

Step 12. Remount the upper rear panel on the cabinet. Secure the panel by applying the screws with your nut-driver.

Step 13. Plug the control panel’s connector back into the main control board. Snap the panel onto the cabinet, then apply the screws at the back to secure.

Step 14. Plug the new power cord into the outlet, then ensure that the machine works properly by turning it on.

Dryers

To replace a damaged power cord in your Maytag dryer, follow the steps below…

Step 1. Disconnect the old power cord from the electrical outlet before starting this procedure in order to prevent electrocution.

Step 2. Use a Torx screwdriver to take out the bolts holding the terminal block access panel. Take the panel off the cabinet and set it aside.

Step 3. Loosen the bolts holding the power cord wires to the terminal block using a 1/4 inch nut-driver. Take out the screw securing the grounding wire.

Step 4. Use a screwdriver to loosen the nuts holding two halves of the strain relief to the back of the cabinet. Take the two halves off the cabinet and set them aside.

Step 5. Take your new power cord out of its packaging. Loosen the screws holding the two halves of the power cord strain relief together.

Step 6. Separate both halves of the strain relief, then push them into the slot at the back of the cabinet. Loosely apply the strain relief screws.

See also  Lock/Unlock GE Washing Machine [How To/Issues & Solutions]

Step 7. Pass the new power cord wires through the strain relief, then properly tighten the nuts.

Step 8. Place each of the wires on their appropriate terminal blocks. Secure the wires by applying the nuts. Put the grounding wire in place on the cabinet, then apply the bolt.

Step 9. Put the terminal access panel back on, then secure it by applying the screws. Plug the new power cord into the electrical outlet, then ensure that the issue has been fixed by running a cycle.

Check out these other articles…

Maytag Washing Machine Error Codes [Proven Solutions]

Maytag Washing Machine Shakes Violently [Causes & Solutions]

Maytag Washing Machine Cycle [Detailed Guide, Problems & Solutions]

Maytag Washing Machine Is Not Spinning [How To Fix]

Clothes Stuck In A Maytag Washer [How To Fix]

Maytag Washing Machine Agitator [Problems, Solutions & Guide]

Maytag Washing Machine Shock Absorber [Issues & Solutions]

3. Failed Noise Filter

To replace a damaged noise filter in your Maytag washing machine, follow the steps below…

Front Loaders

Take the following steps to replace the noise filter in your Maytag front loader washing machine…

Step 1. Disconnect your appliance from the power outlet in order to prevent any chances of electrocution.

Step 2. Using a Torx-20 screwdriver, take out the bolts holding the top panel to the cabinet. Slide the panel backwards about an inch or so, then lift it off the cabinet.

Step 3. Disconnect the power cord wires attached to the line filter at the back of the cabinet (ensure that you note where each connector goes).

Step 4. Loosen the bolts holding the line filter to the cabinet using a 1/4 inch nut-driver. Take the filter out of the cabinet, then discard it.

Step 5. Prepare the new line filter for installation by taking it out of its packaging. Install the new noise filter in the cabinet, then secure it by applying the bolts.

Step 6. Plug the power cord wires into their corresponding terminals on the filter. Place the top panel on the cabinet, then push it forwards. Secure the panel by applying the screws.

Step 7. Reconnect your washing machine to the electrical outlet. To ensure that everything works properly, try running a cycle.

Top Loaders

Take the following steps to replace a damaged noise filter in your Maytag top loader washing machine….

Step 1. In order to prevent any chances of electrocution, it is advised that you disconnect your washing machine from the outlet before starting this procedure.

Step 2. Move your washing machine forwards a bit to get access to the rear. Using a 1/4 inch nut-driver, take out the bolts at the back of the cabinet securing the control panel.

Step 3. Lift the control panel off the cabinet, then disconnect the wire from the main control board. Set the panel aside.

Step 4. Detach the wire harness attached to the noise filter next to the control board. Using a nut-driver, take out the bolt holding the filter to the cabinet. Take the filter off the machine and discard it.

Step 5. Prepare the new noise filter for installation by taking it out of its packaging. Mount the new filter on the cabinet, then apply the screws to secure it.

Step 6. Plug the wire connector into the new filter. Reconnect the control panel’s plug to the main control board.

Step 7. Snap the control panel onto the cabinet, then secure it by applying the bolts at the back using your nut-driver.

Step 8. Plug your washing machine’s power cord into the outlet. Ensure that the issue has been fixed by running a cycle.

4. Failed Control Board

If your Maytag washing machine will not start, it could be as a result of a burnt control board. To check and replace the control board in your washing machine, follow the steps below…

See also  Bosch Washing Machine Door [How To, Issues & Solutions]

Front Loaders

Replace a damaged control board in your Maytag dryer by following the steps below…

Step 1. Prevent any chances of electrocution by disconnecting your washer from the outlet before starting this repair.

Step 2. Loosen the three screws at the back of the machine holding the top panel to the cabinet. Slide the top panel backwards a few inches, then lift it off the cabinet.

Step 3. Pry the cover off the control board at the side of the cabinet. Note the positioning of the connectors attached to the board, then disconnect each one.

Step 4. Pry the control board off the side of the cabinet using a flat-blade screwdriver. Inspect the control board for any signs of damage and buy a new one if needed.

Step 5. Snap the control board onto the side of the cabinet, then reconnect the wire harnesses to their appropriate terminals.

Step 6. Place the cover on the control board. Mount the top panel back on the cabinet, then push it forwards. Secure the panel by applying the screws at the back using a 1/4 inch nut-driver.

Step 7. Reconnect your washing machine to the power outlet, then try turning it on to ensure that the issue has been fixed.

Top Loaders

Take the following steps to replace the control board in your top loader Maytag washing machine…

Step 1. In order to prevent electrical damage, disconnect your appliance from the outlet before starting this repair.

Step 2. Using a 1/4 inch nut-driver, take out the bolts at the back of the machine securing the control panel. Pry the panel off the cabinet, then disconnect the wire harness from the control board.

Step 3. Disconnect all the wires attached to the main control board (ensure that you take note of where they go). Release the wires from the retainers on the control board.

Step 4. Take out the bolts holding the control board to the top of the cabinet using your nut-driver. Discard the old board, then prepare the new one for installation.

Step 5. Mount the new board on the cabinet, then secure it by applying the screws. Plug each wire harness into its appropriate terminal on the new board. Secure the wires in the retainers.

Step 6. Plug the control panel’s wire connector into the new control board. Snap the control panel onto the cabinet, then apply the screws at the back to secure it.

Step 7. Reconnect your washing machine to the power outlet, then ensure that the issue has been fixed by running a wash cycle.

Dryers

To replace a damaged control board in your Maytag dryer, follow the steps below…

Step 1. Disconnect your washing machine from the power outlet in order to prevent any chances of electrocution.

Step 2. Using a 1/4 inch nut-driver, take out the bolts at the back of the machine securing the top panel. Lift the panel off the cabinet and set it aside.

Step 3. Note the positioning of the control board wires at the top of the drum. Disconnect each wire from the board.

Step 4. Take out the screws holding the control board to the cabinet using a 1/4 inch nut-driver. Take the board off the bracket and discard it.

Step 5. Prepare the new board for installation by taking it out of its packaging. Mount the new control board on the support bracket, then secure it by applying the screws with your nut-driver.

Step 6. Plug each wire connector into its appropriate terminal on the new control board. Secure the wires in any retainers on the new board.

Step 7. Remount the top panel on the cabinet, then secure it by applying the screws at the back using a 1/4 inch nut-driver.

Step 8. Plug your washing machine’s power cord back into the outlet. To ensure that the issue has been fixed, try running a wash cycle.
