If your Zanussi washing machine is making noise during cycles, you’ve come to the right place. This detailed guide explains the causes of this issue and provides steps to deal with them…
Table of Contents
Zanussi Washing Machine Is Making Noise — How To Fix
If your Zanussi washing machine is making noise, the following are issues to look for…
1. Zanussi Washing Machine Is Making Noise — Washer Is Unbalanced
If your Zanussi washing machine is making noise, the first thing to do is ensure that the appliance is balanced. Ensure that your washing machine sits on a firm, even surface.
Place a spirit level on top of the machine to ensure that the legs are even. If the machine isn’t balanced, carefully tip it backwards and adjust the legs as needed using a wrench.
Once the legs are properly adjusted, plug your washing machine into the electrical outlet and try running a spin cycle to ensure that the problem has been fixed.
2. Zanussi Washing Machine Is Making Noise — Damaged Drum Weights (Front Loaders)
If your Zanussi washing machine is making noise, it could be that the drum weights are damaged or loose from a previous repair. Follow the steps to replace this part in your Zanussi washing machine…
Rear Weights
Take the following steps to replace the rear weight in your Zanussi front loader washing machine…
Step 1. In order to avoid any chances of leakage and electrocution, ensure that you disconnect your washing machine from the outlet and turn the water taps off before starting this repair.
Step 2. Use pliers to disconnect the COLD and HOT water supply hoses from the ports at the back of the cabinet (it is advised that you keep a rag nearby to clean leaks).
Step 3. Using a Philips screwdriver, take out the nuts holding the rear access panel to the cabinet.
Step 4. Loosen the bolts holding the rear weight to the top of the drum using a 7/16 inch socket wrench. Lift the weight off the drum and set it aside.
Step 5. Prepare the new drum weight for installation by unpacking it. Mount the weight on the drum, then secure it by tightening the nuts.
Step 6. Mount the rear panel back onto the cabinet, then secure it by tightening the Philips screws.
Step 7. Reconnect the HOT and COLD water inlet hoses to the appropriate ports at the back of the machine.
Step 8. Turn the water supply taps on, then plug the power cord into the electrical outlet. Try running a wash cycle to see if your Zanussi washing machine is making noise.
Front Weights
Replace the front weights in your Zanussi washing machine by taking the following steps…
Step 1. In order to avoid electrocution, disconnect your washing machine from the power outlet before starting this procedure.
Step 2. With someone helping you, move your washing machine forwards a bit to gain access to the rear. Use a Philips screwdriver to take out the bolts holding the top panel.
Step 3. Pull the top panel backwards a few inches, then lift it off the cabinet. Slide the soap tray out, then press the little button inside to release it from the housing.
Step 4. Open your washing machine’s door. Wedge a flat-blade screwdriver underneath the metal wire around the door boot seal (you can also use needle-nosed pliers).
Step 5. Pry the door seal off the front panel. Close the door of the machine. Carefully tip the machine backwards and place a support underneath.
Step 6. Use a Philips screwdriver to take out the bolts at the bottom of the front panel. Set your washing machine back onto its feet.
Step 7. Loosen the two nuts on the control panel next to the dispenser opening. Take out the bolts at the top of the front panel.
Step 8. Carefully lift the entire front panel off the cabinet, then disconnect the door switch and user interface board wire connectors.
Step 9. Set the front panel aside. Loosen the bolts holding the lower and upper weights to the front of the drum using a 7/16 inch socket wrench. Lift each weight off the drum carefully and set it aside.
Step 10. Prepare the new drum weights for installation by unpacking them. Mount the new weights onto the drum, then secure them by tightening the bolts.
Step 11. Lift the front panel, then reconnect the door switch and user interface board wire connectors.
Step 12. Snap the front panel onto the cabinet, then use your Philips screwdriver to apply the bolts at the top.
Step 13. Tighten the two nuts on the control panel next to the dispenser opening. Push the soap tray into the housing.
Step 14. Get someone to help you tip your washing machine backwards and support it. Using your Philips screwdriver, apply the bolts at the bottom of the front panel.
Step 15. Set your washing machine back onto its feet, then open the door. Fit the door boot seal around the lip of the front panel.
Step 16. Using your flat-blade screwdriver, fit the retaining wire around the door boot seal.
Step 17. Place the top panel on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.
Step 18. Plug your appliance back into the electrical outlet, then try running a wash cycle to ensure that the noise has stopped.
3. Zanussi Washing Machine Is Making Noise — Damaged Drum Rollers (Dryers)
The the rollers support the drum and help it spin smoothly. If your Zanussi dryer is making noise, it could be that the rollers are damaged. Follow the steps below to replace this part…
Front Rollers
Replace the front rollers in your Zanussi dryer by following the steps below…
Step 1. Disconnect the appliance from the power outlet before starting this repair in order to avoid electrocution.
Step 2. Using a Philips screwdriver, take out the nuts holding the top panel to the cabinet. Pull the panel backwards about an inch or so, then lift it off the cabinet.
Step 3. Loosen the bolts at the top of the control panel. Pry the panel off the cabinet, then disconnect the wire harness.
Step 4. Open the door of your dryer, then use your screwdriver to take out the bolts holding the lint filter housing.
Step 5. Get someone to help you tip your washing machine backwards and support. Use your Philips screwdriver to take out the bolts at the bottom of the front panel.
Step 6. Set your washing machine back onto its feet. Loosen the bolts at the top of the front panel.
Step 7. Carefully lift the front panel off the cabinet. Disconnect the door switch wire harness attached to the panel. Set the front panel aside.
Step 8. Disconnect the user interface and door switch wire connectors from the main control board at the top of the drum.
Step 9. Using your Philips screwdriver, loosen the bolts holding the control board support bracket to the front bulkhead. Move the board out of place and support it.
Step 10. Loosen the bolts holding the front bulkhead to the cabinet. Carefully lift the bulkhead off.
Step 11. Secure the roller shaft on the front bulkhead using a 1/4 inch Allen wrench. To release the roller, loosen the bolt at the other side of the bulkhead. Slide the roller off the shaft and discard it.
Step 12. Prepare the new drum roller for installation by unpacking it. Mount the new roller on the front bulkhead, then tighten the 14mm bolt at the back.
Step 13. Lift the front bulkhead, then carefully mount it on the cabinet. Secure the bulkhead by applying the Philips screws.
Step 14. Move the main control board bracket back against the front bulkhead, then secure it by tightening the Philips screws.
Step 15. Reconnect the door switch and user interface wire connectors to the main control board.
Step 16. Lift the front panel, then reconnect the door switch wire harness. Snap the panel onto the front of the cabinet. Using your Philips screwdriver, tighten the bolts at the top of the front panel.
Step 17. Get someone to help you tip the washing machine backwards and support it. Use your screwdriver to apply the nuts at the bottom of the panel.
Step 18. Carefully set the machine back onto its feet. Open the door of the dryer, then tighten the nuts to secure the lint filter housing.
Step 19. Plug the wire harness back into the control panel. Snap the panel onto the front of the cabinet. With your Philips screwdriver, tighten the nuts at the top of the panel.
Step 20. Mount the top panel on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.
Step 21. Reconnect your dryer to the power outlet, then try running a spin cycle to see if your Zanussi dryer is making noise.
Rear Rollers
Replace a rear drum roller in your Zanussi dryer by following the steps below…
Step 1. Prevent any chances of electrocution by disconnecting your appliance from the power outlet before starting this procedure.
Step 2. Go to the back of the machine, then loosen the bolts holding the top cover using a Philips screwdriver. Slide the top cover backwards about an inch or so, then lift it off the cabinet.
Step 3. Take out the bolts at the top of the control panel. Pry the panel off the front of the dryer, then disconnect the wire harness attached to it.
Step 4. With someone assisting you, tip the appliance backwards a bit and support it. Use your screwdriver to take out the nuts at the bottom of the front panel.
Step 5. Carefully lower the dryer onto the floor. Open the door of the machine, then take out the bolts holding the lint filter housing.
Step 6. Loosen the screws at the top of the front panel. Carefully lift the entire front panel off the machine. Detach the door switch wire harness at the other side of the front panel.
Step 7. Disconnect the user interface and door lock wire connectors from the main control board mounted on the drum.
Step 8. Use a Philips screwdriver to take out the bolts holding the control board’s support bracket to the front bulkhead. Move the bracket out of place and support it.
Step 9. Loosen the nuts securing the bulkhead to the front of the drum. Carefully lift the bulkhead off the machine and set it aside.
Step 10. Carefully reach underneath the drum, then push the idler pulley inwards (this will release the tension on the drive belt).
Step 11. Unhook the drive belt from the motor pulley and idler pulley. Carefully lift the drum and belt out of the cabinet.
Step 12. Use your Philips screwdriver to take out the nuts holding the mounting bracket to the top of the rear panel.
Step 13. Turn the water supply tap off, then loosen the water hose from the port at the back of the machine using pliers.
Step 14. Take out the bolts holding the lower rear access panel. Lift the panel off the dryer and set it aside.
Step 15. Use your Philips screwdriver to loosen the nuts holding the power cord wires to the terminal block in the machine. Detach each wire from the terminal block (ensure that you note where each wire goes).
Step 16. Use your screwdriver to loosen all the bolts holding the main rear panel to the cabinet. Lift the panel off the machine carefully, then set it aside.
Step 17. Using a 1/4 inch Allen wrench, secure the shaft of the drum roller you want to replace. Use a 14mm socket to loosen the drum roller bolt at the back of the rear bulkhead.
Step 18. Pull the old roller off the bulkhead and discard it. Prepare the new drum roller for installation by unpacking it.
Step 19. Mount the roller on the cabinet, then use your 14mm socket wrench to apply the bolt.
Step 20. Carefully remount the rear access panel onto the cabinet. Secure the panel by tightening the Philips screws.
Step 21. Plug each of the power cord wires into the terminal block. Secure the wires by applying the screws.
Step 22. Snap the lower rear access panel onto the cabinet, then tighten the Philips screws to secure it.
Step 23. Reconnect the water supply hose to the port at the back of the machine. Turn the water tap back on.
Step 24. Place the mounting bracket back on the rear panel, then use your Philips screwdriver to tighten the nuts.
Step 25. Carefully lift the drum and drive belt, then guide them into the cabinet. Reach under the drum, then hook the belt onto the idler and motor pulleys in a zig-zag formation.
Step 26. Ensure that the belt is properly aligned by slowly rotating the drum. Lift the front bulkhead, then mount it on the drum. Secure the bulkhead by tightening the screws.
Step 27. Move the control board bracket back against the front bulkhead, then use your Philips screwdriver to apply the bolts.
Step 28. Reconnect the door switch and user interface wire connectors to the main control board.
Step 29. Lift the front panel carefully, then plug the door lock wire connector back in. Mount the panel onto the cabinet, then tighten the screws at the top.
Step 30. Open the door of the dryer, then tighten the nuts to secure the lint filter housing.
Step 31. Get someone to help you tip your washing machine backwards and support it. Tighten the nuts at the bottom of the front panel.
Step 32. Lower your washing machine back onto the floor. Reconnect the wire harness to the user control panel.
Step 33. Snap the panel onto the front of the cabinet, then use your screwdriver to apply the bolts at the top.
Step 34. Place the top panel back on the machine. Secure the top panel by applying the Philips screws.
Step 35. Plug your dryer back into the electrical outlet. Try running a cycle to see if your Zanussi washing machine is making noise.
Note: Some of the steps in the section above will be a bit different depending on the model of your washing machine.
4. Zanussi Washing Machine Is Making Noise — Damaged Drum Seal (Dryers)
Your Zanussi dryer will make noise if the seal on the drum opening is damaged. Follow the steps below to replace this part…
Step 1. In order to avoid any chances of electrocution, ensure that you disconnect your washing machine from the power outlet before starting this repair.
Step 2. Go to the back of your machine, then use a Philips screwdriver to take out the bolts holding the top panel to the cabinet. Pull the panel backwards and lift it off the cabinet.
Step 3. Get someone to help you tip your washing machine backwards and support it. Use your screwdriver to take out the nuts at the bottom of the front panel.
Step 4. Set your machine back onto its feet. Open the dryer’s door, then use your screwdriver to take out the nuts securing the lint filter housing.
Step 5. Take out the bolts at the top of the front panel. Lift the panel off the cabinet carefully, then disconnect the door switch wire harness.
Step 6. Disconnect the user interface board and door switch wire connectors from the main control board at the top of the drum.
Step 7. Loosen the screws holding the control board support bracket to the front bulkhead. Move the bracket out of position and support it.
Step 8. Take out the nuts holding the front bulkhead to the cabinet. Carefully lift the bulkhead off the machine and set it aside.
Step 9. Reach under the drum carefully, then push the idler pulley inwards to release the tension on the drive belt.
Step 10. Unhook the belt from the motor and idler pulleys. Lift the belt and drum out of the cabinet carefully.
Step 11. Set the drum on the floor facing upwards. Using a putty knife, pry the old seal off the drum opening. Carefully scrape off any seal residue on the drum opening.
Step 12. Prepare the new drum seal for installation by unpacking it. Apply a layer of the provided adhesive to the drum opening. Leave the adhesive to set for a minute or two.
Step 13. Carefully fit the new drum seal around the drum opening (ensure that the seal’s leather band faces outwards).
Step 14. In order to let adhesive dry properly, leave the drum for about 30 minutes. Once the adhesive is dryer, carefully lift the belt and drum, then guide them into the cabinet.
Step 15. Reach under the drum carefully and hook the belt onto the motor and idler pulleys in a zig-zag formation. Rotate the drum by hand to ensure that the belt is properly aligned.
Step 16. Carefully mount the front bulkhead on the drum, then secure it by tightening the Philips screws.
Step 17. Place the control board’s support bracket against the front bulkhead, then secure it by tightening the Philips screws.
Step 18. Plug the wire harnesses back into the main control board. Lift the front panel, then plug the door switch wire harness in.
Step 19. Snap the front panel onto the cabinet, then use your Philips screwdriver to apply the bolts at the top.
Step 20. Open your dryer’s door, then tighten the nuts to secure the lint filter housing. Tip the machine backwards carefully, then apply the bolts at the bottom.
Step 21. Carefully set your washing machine back onto its feet. Plug the wire connector into the control panel. Snap the panel onto the front of the machine, then use your Philips screwdriver to apply the bolts at the top.
Step 22. Mount the top cover on the cabinet, then push it forwards. Use your screwdriver to apply the bolts at the back of the panel.
Step 23. Reconnect your appliance to the power outlet. To see if your Zanussi washing machine is making noise, try running a wash cycle.
Note: Please keep in mind that the steps in the section above will be a bit different depending on the model of your dryer.
5. Zanussi Washing Machine Is Making Noise — Damaged Suspension Spring (Front Loaders)
Your washer is held to the top of the cabinet by two suspension springs. If your washer’s drum bangs around a lot, it could be that the spring is damaged. Follow the steps below to replace a damaged suspension spring in your Zanussi washing machine…
Step 1. Disconnect your appliance from the electrical outlet before starting this repair, in order to prevent electrocution.
Step 2. Go to the back of the machine, then take out the bolts holding the top panel using a Philips screwdriver. Pull the panel backwards a few inches and lift it off the cabinet.
Step 3. Turn the COLD and HOT water supply taps off. Disconnect the water supply hoses from the ports at the back of the machine (some water may spill, so ensure that you keep a rag nearby).
Step 4. Take out the nuts holding the vibration dampening block to the top of the machine. Lift the block off the machine and set it aside.
Step 5. Disconnect the power cord’s wire harness and grounding wire. Use needle-nosed pliers to release the power cord wire retainer from the upper support rail.
Step 6. Use your screwdriver to loosen the nut holding the retainer to the drain hose. Slide the retainer off the hose and set it aside.
Step 7. Loosen the bolts holding the support rail to the top of the rear panel. Lift the rail off and set it aside.
Step 8. Take out the nuts securing the rear access panel. Carefully lift the rear panel off the cabinet and set it aside (the drain hose will still be attached).
Step 9. Pull the soap tray out of the housing, then press the little button inside to release it from the housing.
Step 10. Take out the bolts on the control panel next to the dispenser’s opening. Reach into the cabinet, then loosen the screw-clamp holding the outlet hose to the dispenser. Detach the hose from the dispenser.
Step 11. Note the positioning of the wires attached to the water inlet valve, then disconnect each one.
Step 12. Loosen the nuts on the support rail securing the dispenser and inlet valve assembly. Cut the zip-tie securing the hoses to the dispenser assembly.
Step 13. Use pliers to squeeze the retaining clamp holding the vent hose to the dispenser. Detach the hose from the dispenser assembly.
Step 14. Pull the dispenser and inlet valve assembly out of the cabinet. Use your screwdriver to take out the nut securing the retaining strap to the right suspension spring.
Step 15. With the strap taken out, apply the bolts to secure the support rail. Get someone to help you lift and support the tub.
Step 16. If still intact, carefully lift the suspension spring and unhook it from the cabinet. Unhook the other end of the spring from the tub, then pull it out of the cabinet.
Step 17. Prepare the new suspension spring for installation by unpacking it. Carefully hook the new spring onto the tub and and cabinet.
Step 18. Loosen the nuts holding the support rail. Put the spring retaining strap in place, then use your Philips screwdriver to tighten the bolts.
Step 19. Carefully lower the tub assembly, then replace the second spring if needed. Move the dispenser and inlet valve assembly back into the cabinet.
Step 20. Reconnect the vent hose to the dispenser assembly. Secure the connection by sliding the spring clamp into place.
Step 21. Circulation and air vent hoses to the dispenser’s housing using a zip-tie. Push the dispenser back in place, then apply the nuts to secure it to the upper support rail.
Step 22. Apply the nuts on the control panel next to the dispenser’s opening. Plug each wire harness into its appropriate terminal on the valve assembly.
Step 23. Connect the outlet hose to the port at the bottom of the dispenser. Secure the connection by tightening the screw-clamp.
Step 24. Push the soap tray into the dispenser housing. Snap the rear access panel onto the cabinet, then use your Philips screwdriver to apply the nuts.
Step 25. Slide the retainer onto the drain hose, then apply the Philips screw to secure it. Place the support rail on the rear panel, then tighten the bolts.
Step 26. Snap the power cord’s wire retainer into the slot on the upper support rail. Plug the power cord wire harness and grounding wire back in.
Step 27. Place the top panel on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.
Step 28. Reconnect the HOT and COLD water supply hoses to the ports at the back of the washer (in order to avoid leaks, ensure that the hoses are properly attached).
Step 29. Plug your washing machine into the electrical outlet, then turn the water supply taps on. To ensure that the noise has stopped, try running a wash cycle.
6. Zanussi Washing Machine Is Making Noise — Broken Spider Arm (Front Loaders)
The spider arm is at the back of the inner tub, and helps it spin smoothly. If your washing machine makes noise when turning the drum by hand, it’s most likely the result of a broken spider. Follow the steps below to replace this part…
Step 1. In order to avoid leakage and electrocution, ensure that you disconnect your washing machine from the power outlet and turn the water taps off before starting this procedure.
Step 2. Using a pair of pliers if needed, disconnect the COLD and HOT water supply hoses from the ports at the back of the machine (ensure that you keep a rag nearby to clean any leaks).
Step 3. With a Philips screwdriver, take out the bolts holding the rear access panel to the cabinet. Carefully lift the panel off the machine and set it aside.
Step 4. Loosen the nuts holding the top cover. Pull the panel backwards about an inch or so, then lift it off the cabinet.
Step 5. Go to the front of the machine, then take out the screws holding the lower front access panel. Lift the panel off the cabinet and set it aside.
Step 6. Open the door of your washing machine. Carefully wedge a flat-blade screwdriver under the retaining band around the door seal.
Step 7. Carefully work the screwdriver around until the wire pops off. Pry the door seal off the lip of the front panel.
Step 8. Using pliers if needed, untwist the retaining clamp holding the door seal to the inlet tube. Disconnect the seal from the tube.
Step 9. Push a 6-point 1/2 socket onto the pointed end of the upper shock absorber mounting pins. Pull the pins out from the other end using pliers.
Step 10. Detach each shock absorber from its mount at the bottom of the tub. Use a flat-blade screwdriver to release the pressure chamber from the retainer at the side of the tub.
Step 11. Detach the wire connector plugged into the drive motor. Cut the zip-tie holding the motor wires to the bottom of the tub.
Step 12. Unhook the drive belt from the motor and drive pulleys, then set it aside. Use a socket wrench to take out the bolts securing the motor to the tub. Lift the motor off carefully, then set it aside.
Step 13. Place a towel underneath the tub to catch leaks. Using your Philips screwdriver, loosen the screw-clamp holding the sump hose to the bottom of the tub. Detach the hose from the tub.
Step 14. Pull the vent hose off the port at the top of the drum. With a 13mm socket wrench, loosen the nuts holding the weight to the upper rear of the tub. Carefully lift the weight off the machine and set it aside.
Step 15. Use your screwdriver to take out the bolts holding the motor control board to the cabinet. Pull the board out of place, then disconnect the wires attached (ensure that you note where each plug goes).
Step 16. Loosen the bolts securing the suspension spring retaining straps. Take the straps off and set them aside.
Step 17. With someone assisting you, carefully lift the two suspension springs and unhook them from the cabinet.
Step 18. Carefully guide the drum assembly out of the cabinet. Unhook the two springs from the tub, then set the assembly on the floor facing upwards.
Step 19. With a 3/8 inch socket wrench, loosen the nuts securing the two halves of the outer tub together. Lift the front half off the assembly and set it aside (the weights will still be attached).
Step 20. Turn the tub assembly over and set it face-down on the floor. Loosen the nut securing the drive pulley to the inner tub shaft using a 9/16 inch socket wrench.
Step 21. Lift the rear half of the outer tub off the assembly (if you have difficulty with this, apply some penetrating oil to the shaft).
Step 22. Using a socket wrench, loosen the six nuts holding the spider arm to the inner tub (depending on the model of your machine, you may need to replace the entire inner tub).
Step 23. Lift the spider assembly off the inner tub and discard it. Prepare the new spider arm for installation by unpacking it.
Step 24. Mount the spider arm on the inner tub, then use your socket wrench to apply the bolts.
Step 25. Carefully lower the rear half of the outer tub onto the inner tub shaft. Place the drive pulley on the inner tub shaft, then apply the 9/16 inch bolt.
Step 26. Turn the tub assembly over. Lower the front half of the outer tub onto the assembly, then apply the 3/8 inch bolts.
Step 27. Lift the tub upright, then attach the suspension springs to the mounts. Get someone to help you lift the tub assembly and guide it back into the cabinet.
Step 28. Carefully lift the two springs and hook them onto the cabinet. Mount the spring retaining straps on the cabinet, then apply the nuts using your Philips screwdriver.
Step 29. Push each shock absorber into its mount at the bottom of the tub. Snap the upper mounting pins into the shock absorbers.
Step 30. Push the vent hose into the port at the top of the drum. Go to the back of the machine, then reconnect the wires to the motor control board.
Step 31. Install the board in the cabinet, then apply the nuts using your Philips screwdriver.
Step 32. Place the rear weight on the drum, then use your socket wrench to tighten the screws.
Step 33. Reach underneath the tub and reconnect the sump hose. Tighten the screw-clamp to secure the hose.
Step 34. Using a zip-tie, secure the motor wires to the bottom of the tub. Carefully remount the drive motor at the bottom of the tub, then secure it by applying the nuts.
Step 35. With the grooved side turned inwards, loop the drive belt around the drive pulley and motor pulley. Rotate the belt to ensure it is properly aligned.
Step 36. Plug the wire harness into the drive motor. Go to the front of the machine, then refit the door seal around the water inlet port. Twist the retaining wire using pliers.
Step 37. Fit the door boot seal around the lip the front panel. Using needle-nosed pliers or a flat-blade screwdriver, fit the retaining wire around the door seal.
Step 38. Snap the lower front panel back onto the cabinet, then use your Philips screwdriver to apply the nuts.
Step 39. Place the top panel on the cabinet, then apply the bolts at the back using your screwdriver.
Step 40. Snap the rear access panel onto the cabinet. Secure the panel by applying the screws. Reconnect the water inlet hoses to their corresponding ports
Step 41. Plug your appliance into the power outlet, then turn the water taps back on. To ensure that the noise has stopped, try running a spin cycle.
7. Zanussi Washing Machine Is Making Noise — Failed Shock Absorbers (Front Loaders)
If your Zanussi washing machine is making noise, the next cause to look for is a damaged shock absorber. The shock absorbers help keep the tub balanced, and prevent it from shaking excessively. Follow the steps below to replace a damaged shock absorber in you Zanussi washing machine…
Front Shock Absorber
Replace a front shock absorber in your Zanussi washing machine by following the steps below…
Step 1. In order to prevent electrical damage, ensure that you disconnect your washing machine from the power outlet before starting this repair.
Step 2. Go to the back of the machine, then loosen the bolts holding the top panel using a Philips screwdriver. Pull the panel backwards a few inches, then lift it off.
Step 3. Go to the front of the machine, then pull the soap tray out. Press the little tab in the tray to release it from the housing.
Step 4. Use a Philips screwdriver to take out the two bolts next to the dispenser opening on the control panel.
Step 5. Take out the nuts holding the control panel to the front of the cabinet. Pry the panel off the mounting bracket. Disconnect the wire harness from the panel, then set it aside.
Step 6. Using a flat-blade screwdriver, pry the cover off the main control board. Disconnect the door switch wire harness from the control board.
Step 7. Open your washing machine’s door. Using a flat-blade screwdriver or needle-nosed pliers, carefully pry out the retaining band around the door seal.
Step 8. Peel the door seal off the lip of the front panel. Get someone to help you tip your washing machine backwards and support it.
Step 9. Loosen the bolts at the bottom of the front panel. Take the support out from underneath the machine, then lower your appliance.
Step 10. Take out the Philips screws at the top of the front panel. Carefully lift the entire panel off the cabinet and set it aside.
Step 11. Push a 1/2 inch socket onto the pointed end on the lower mounting pin of the shock absorber you want to replace. Pull the pin out from the other end using pliers. Repeat this process with the top mounting pin.
Step 12. Pull the lower and upper parts of the shock absorber out of the tub and cabinet. Discard the old shock absorber, then prepare the new one for installation by unpacking it.
Step 13. Push the new shock absorber into the mount on the cabinet and at the bottom of the tub. Push the lower and upper mounting pins into the shock absorber.
Step 14. Lift the front panel carefully, then snap it onto the cabinet. Apply the Philips screws at the top of the panel.
Step 15. Tip the appliance backwards carefully and support it. Use your screwdriver to tighten the nuts at the bottom of the front panel.
Step 16. Open the door of your washing machine, then carefully fit the door boot seal around the lip of the front panel. Use a flat-blade screwdriver to fit the retaining wire around the seal.
Step 17. Plug the wire harness into the control panel, then snap the panel onto the front of the machine.
Step 18. Plug the door switch wire harness into the motor control board. Snap the cover onto the board.
Step 19. Use your Philips screwdriver to apply the nuts at the top of the control panel. Tighten the screws next to the dispenser opening on the control panel.
Step 20. Push the soap tray into the dispenser. Mount the top panel on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.
Step 21. Plug your washing machine into the power outlet. To ensure that the noise has stopped, try running a spin cycle.
Rear Shock Absorber
Replace a rear shock absorber in your front loader Zanussi washing machine by following the steps below…
Step 1. In order to avoid electrical damage and leakage, make sure to disconnect your washing machine from the power outlet and turn the water faucets off before starting this repair.
Step 2. Go to the back of the cabinet, then disconnect the COLD and HOT water supply hoses from the ports (ensure that you have a rag nearby in case water spills).
Step 3. Using a Philips screwdriver, take out the nuts holding the top panel to the cabinet. Slide the panel backwards about an inch or so, then lift it off.
Step 4. Use your screwdriver to take out the bolts holding the vibration dampening block to the top of the cabinet. Carefully lift the block off and set it aside.
Step 5. Loosen the bolt holding the retainer to the drain hose. Pull the retainer off and set it aside.
Step 6. Detach the power cord’s grounding wire and wire harness. Release the wire retainer from the support rail using needle-nosed pliers.
Step 7. Take out the nuts holding the upper support rail to the rear panel. Lift the rail off the cabinet and set it aside.
Step 8. Loosen the nuts holding the rear access panel to the cabinet. Lift the panel off the machine and support it on the cabinet.
Step 9. Push a 1/2 inch socket onto the pointed end on the lower mounting pin of the rear shock absorber you want to replace. Pull the pin through the other end using pliers.
Step 10. Push the socket onto the pointed end of the upper mounting pin, then pull it out as well. Pull the old shock absorber out of the mounts at the bottom of the tub and on the cabinet.
Step 11. Prepare the new shock absorber for installation by unpacking it. Push the shock absorber into the mounts on the cabinet and tub. Secure the shock absorber by pushing the mounting pins into place.
Step 12. Snap the rear access panel onto the cabinet, then use your Philips screwdriver to apply the nuts.
Step 13. Push the retainer back onto the drain hose, then apply the Philips screw to secure it. Place the upper support rail on the rear panel, then tighten the screws.
Step 14. Snap the power cord wire retainer into the upper support rail. Plug the power cord’s wire harness and grounding wire back in.
Step 15. Put the vibration dampening block in place, then use your Philips screwdriver to apply the bolts.
Step 16. Reconnect the COLD and HOT water supply hoses to the corresponding ports at the back of the cabinet (in order to avoid leakage, ensure that each hose is properly attached).
Step 17. Mount the top cover on the machine, then secure it by tightening the Philips screws.
Step 18. Plug your washing machine into the electrical outlet, then turn the COLD and HOT water taps back on. See if your Zanussi washing machine is making noise by running a spin cycle.
Note: Please keep in mind that some of the steps above may be a bit different depending on the model of your washing machine.
8. Zanussi Washing Machine Is Making Noise — Broken Drive Pulley
If your Zanussi washing machine is making noise, another important cause to look for is a cracked drive pulley. For detailed steps on how to replace the drive pulley in your Zanussi washing machine, read this article: Zanussi Washing Machine Spin.
9. Zanussi Washing Machine Is Making Noise — Damaged Motor Bearings
If your Zanussi washing machine is making noise, the final cause to look for is damaged motor bearings. Follow the steps below to inspect the motor bearings in your washing machine…
Top Loaders
Inspect the motor bearing in your top loader Zanussi washing machine by following the steps below…
Step 1. Prevent any chances of electrical damage by disconnecting your washing machine from the power outlet before starting this repair.
Step 2. Using a Philips screwdriver, take out the bolts at the bottom of the front panel. Slide the panel downwards, then lift it off the cabinet.
Step 3. Loosen the screws holding the motor control board. Pull the board out of place.
Step 4. Reach underneath the mounting base, then pull the drive belt off the pulleys. Use a screwdriver to loosen the nuts holding the motor shield to the side of the tub. Pull the shield out of place and set it aside.
Step 5. Disconnect the wire harness attached to the drive motor. Take out the bolts holding the motor to the mounting base using a 5/16 inch socket wrench.
Step 6. Carefully pull the motor out of the cabinet. Try rotating the motor pulley by hand. If you notice a grinding noise when turning the pulley, the motor bearings are damaged. To fix this issue, you’ll need to buy a new motor.
Step 7. Once you’ve acquired the new drive motor, install it in the cabinet, then secure it to the base by tightening the 5/16 inch bolts.
Step 8. Plug the wire harness into the new drive motor. Move the motor shield into place, then apply the Philips screws.
Step 9. With the grooved side facing inwards, loop the drive belt around the pulleys under the mounting base. Rotate the belt to ensure it is aligned.
Step 10. Push the motor control board back in place. Secure the board to the cabinet by applying the Philips screws.
Step 11. Mount the front panel onto the cabinet. Use your screwdriver to tighten the nuts at the bottom of the panel.
Step 12. Plug your washing machine back into the electrical outlet. To find out if your Zanussi washing machine is making noise, try running a wash cycle.
Front Loaders
Inspect the motor bearing in your front loader Zanussi washing machine by following the steps below…
Step 1. In order to avoid electrocution and leakage, ensure that you disconnect your appliance from the power outlet and turn the water taps off before starting this repair.
Step 2. Using a pair of pliers if needed, disconnect the HOT and COLD water hoses from the ports at the back of the cabinet (ensure that you keep a rag nearby in case water spills).
Step 3. Use a Philips screwdriver to take out the bolts holding the top panel. Slide the panel backwards a few inches, then lift it off the cabinet.
Step 4. Loosen the nuts holding the vibration dampening block to the top of the machine. Lift the block off and set it aside.
Step 5. Using needle-nosed pliers, release the power cord wire retainer from the support rail at the top of the rear panel.
Step 6. Disconnect the power cord’s wire harness and grounding wire. Take out the Philips screws holding the support rail to the rear panel. Lift the rail off the machine.
Step 7. Loosen the nut holding the retainer to the drain hose. Pull the retainer off and set it aside.
Step 8. Use your screwdriver to take out the nuts holding the rear panel to the cabinet. Carefully lift the panel off and support it against the cabinet.
Step 9. Unhook the drive belt from the motor pulley and drive pulley. Disconnect the wire harness connected to the drive motor.
Step 10. Using a socket wrench, loosen the bolts holding the drive motor to the bottom of the tub. Carefully lift the motor off and pull it out of the cabinet.
Step 11. Try rotating the motor pulley by hand. If the motor make a grinding noise while you turn the pulley, it indicates that the motor bearings are damaged. You’ll need to replace the motor to fix this issue.
Step 12. Once you’ve gotten your new washing machine drive motor, carefully mount it at the bottom of the tub, then tighten the bolts with your socket wrench.
Step 13. Plug the wire harness into the new drive motor. Loop the belt around the drive pulley and motor pulley (ensure that the belt is turned with the grooved side facing inwards).
Step 14. To ensure that the belt is properly aligned, rotate the drive pulley by hand. Lift the rear panel and snap it onto the cabinet. Secure the panel by applying the Philips screws.
Step 15. Slide the retainer onto the drain hose, then use your Philips screwdriver to apply the nut.
Step 16. Place the upper support rail on the rear panel, then apply the Philips screws to secure it. Snap the power cord wire retainer into the support rail.
Step 17. Reconnect the power cord’s grounding wire and wire harness. Mount the vibration block on the cabinet. Use your screwdriver to tighten the nuts on the block.
Step 18. Place the top cover on the machine, then push it into place. Tighten the bolts at the back of the cabinet to secure the panel.
Step 19. Reconnect the HOT and COLD hoses to their corresponding ports at the back of the machine.
Step 20. Turn the water taps on, then plug your washing machine into the electrical outlet. To find out if your Zanussi washing machine is making noise, try running a spin cycle.
Dryers
Take the following steps to inspect the motor bearings in your Zanussi dryer…
Step 1. Avoid any chances of electrocution by disconnecting your appliance from the outlet before starting this procedure.
Step 2. Go to the back of the cabinet, then loosen the bolts holding the top cover using a Philips screwdriver.
Step 3. Pull the cover backwards about an inch or so, then lift it off the cabinet. Use your screwdriver to take out the nuts at the top of the user control panel.
Step 4. Disconnect the wire harness from the control panel, then set the panel aside. Open the dryer’s door, then loosen the screws holding the lint filter housing.
Step 5. With someone assisting you, carefully tip your washing machine backwards and support it. Loosen the Philips screws at the bottom of the front panel.
Step 6. Lower your washing machine back onto the floor. Take out the bolts at the top of the front panel.
Step 7. Carefully lift the front panel off the cabinet. Disconnect the door switch wire harness attached to the front panel, then set the panel aside.
Step 8. Detach the drum light and user interface board wire connectors from the main control board at the top of the drum.
Step 9. Take out the nuts on the front bulkhead holding the control board’s support bracket. Move the control board bracket out of place and support it.
Step 10. Using your Philips screwdriver, loosen the bolts holding the front bulkhead to the drum. Carefully lift the bulkhead off the machine and set it aside.
Step 11. Reach under the drum carefully, then push the idler pulley inwards (this releases the tension on the drive belt). Unhook the belt from the idler and motor pulleys.
Step 12. Lift the drive belt and drum out of the cabinet carefully, then set them aside. Unplug the wire harness attached to the drive motor.
Step 13. Secure the motor shaft using pliers. Loosen the blower wheel from the housing using a 7/16 inch socket wrench.
Step 14. Use a flat-blade screwdriver to pry off the retaining clamps holding the drive motor to the cabinet. Carefully pull the drive motor out of place.
Step 15. Try turning the motor pulley by hand. If a grinding or squeaking noise comes from the motor while turning, it indicates that the bearings have failed. To fix this issue, you’ll need to replace the entire drive motor.
Step 16. Once you’ve gotten your new drive motor, install it in the cabinet and snap the front and rear retaining clips.
Step 17. Plug the wire harness into the drive motor. Secure the motor shaft and tighten the blower wheel using your socket wrench.
Step 18. Lift the drum and belt into the cabinet. Reach underneath the drum, then loop the belt around the motor and idler pulleys in a zig-zag formation.
Step 19. To ensure that the belt is properly aligned, try rotating the drum by hand. Mount the front bulkhead on the drum, then use your Philips screwdriver to apply the bolts.
Step 20. Place the control board’s support bracket back against the front bulkhead, then apply the screws.
Step 21. Reconnect the door switch and drum light wire connectors to the main control board.
Step 22. Lift the front panel carefully, then plug the door lock wire connector in. Snap the front panel onto the front of the cabinet.
Step 23. Using your Philips screwdriver, apply the nuts at the top of the front panel. Open the door of your machine, then tighten the bolts to secure the lint filter housing.
Step 24. Get someone to help you tip your washing machine backwards and support it. Apply the nuts at the bottom of the front panel.
Step 25. Lower your dryer to the floor. Plug the user interface wire connector into the control panel.
Step 26. Snap the panel onto the front of the cabinet, then apply the nuts at the top using your Philips screwdriver.
Step 27. Place the top cover on the cabinet, then push it forwards. Tighten the nuts at the back of the panel.
Step 28. Plug your machine into the electrical outlet. To ensure that the issue has been fixed, try running a spin cycle.
