If your AEG washing machine is leaking, this guide is for you. In this detailed article, we discuss the primary causes of leakage in your washer and provide detailed steps to fix them…
Table of Contents
AEG Washing Machine Is Leaking — How To Fix
If your AEG washing machine is leaking, the following are issues to look for…
1. AEG Washing Machine Is Leaking — Loose/Damaged Water Inlet Hoses
If your AEG washing machine is leaking from the bottom, the first thing to do is check to ensure that the water inlet hoses are properly connected and not damaged. If you notice water coming out of the hoses, you’ll need to replace them.
2. AEG Washing Machine Is Leaking — Damaged Detergent Dispenser
A cracked dispenser assembly could be another reason your AEG washing machine is leaking. The steps below show you how to replace this part…
Step 1. Before starting this repair, ensure that you shut the water taps and disconnect the power cord from the outlet in order to avoid leaks and electrocution.
Step 2. Go to the back of the machine, then use pliers to disconnect the water inlet hoses (it is advised that you keep a towel nearby to clean leaks).
Step 3. With a Philips screwdriver, loosen the nuts securing the top cover using a Philips screwdriver. Pull the panel backwards a few inches and lift it off the machine.
Step 4. Use your screwdriver to take out the nut securing the retainer to the drain hose. Loosen the screws holding the vibration block to the top of the machine (your machine may not have this).
Step 5. Unplug the power cord’s wire harness and grounding wire at the back of the cabinet. Use a pair of needle-nosed pliers to release the power cord’s wire retainer from the cabinet.
Step 6. Loosen the screws securing the upper support rail mounted on the rear access panel. Lift the rail off and set it aside.
Step 7. Take out the screws securing the rear panel to the machine. Lift the panel off the cabinet and set it aside (note that the drain hose will still be attached to the rear panel).
Step 8. Go to the front of the machine, then slide the soap tray out. Press the little button inside to release the tray from the housing.
Step 9. Loosen the screws next to the dispenser’s opening on the control panel. Note the position of the wires connected to the water inlet valve, then disconnect each one.
Step 10. Use a Philips screwdriver to take out the nuts holding the inlet valve assembly to the dispenser. Pull the valve off the dispenser and set it aside.
Step 11. Cut the zip-tie holding the tubes to the dispenser assembly. Use your Philips screwdriver to loosen the screw-clamp securing the outlet hose to the dispenser housing.
Step 12. Pull the hose off the dispenser. Take out the screws holding the dispenser assembly to the support rail. Carefully pull the dispenser out of the machine, then discard it.
Step 13. Prepare the new dispenser assembly for installation by taking it out of its packaging. Push the new dispenser into the cabinet.
Step 14. Connect the outlet hose to the port at the bottom of the dispenser. Secure the hose by tightening the screw-clamp.
Step 15. Secure the tubes to the new dispenser using a zip-tie. Using your Philips screwdriver, apply the nuts on the support rail to secure the new dispenser.
Step 16. Apply the screws on the control panel next to the dispenser’s opening. Push the soap tray into the dispenser.
Step 17. Remount the water inlet valve on the dispenser, then use your Philips screwdriver to apply the bolts.
Step 18. Plug each wire connector into its appropriate terminal on the valve assembly. Lift the rear access panel, then place it on the cabinet. Secure the panel by applying the Philips screws.
Step 19. Mount the support rail on the rear panel, then apply the screws using your Philips screwdriver. Snap the power cord’s wire retainer into the slot on the support rail.
Step 20. Plug the power cord’s grounding wire and wire connector back in. Place the vibration block on the cabinet, then secure it by applying the nuts.
Step 21. Reconnect the COLD and HOT water inlet hoses to the corresponding ports (in order to avoid leakage, ensure that each hose is properly connected.
Step 22. Place the top cover on the machine, then push it forwards. Secure the top panel by applying the Philips screws at the back. Push the retainer onto the drain hose, then apply the nut to secure it.
Step 23. Turn the water taps back on, then reconnect the power cord to the electrical outlet. Find out if your AEG washing machine is leaking by running a wash cycle.
3. AEG Washing Machine Is Leaking — Damaged Dispenser Hose
If your AEG washing machine is leaking, the next cause to look for is a damaged dispenser outlet hose. Follow the steps below to inspect and replace this part…
Step 1. Avoid any chances of electrocution and leakage by disconnecting your washing machine from the power outlet and turning the water faucets off before starting this repair.
Step 2. Go to the back of the cabinet, then disconnect the HOT and COLD water supply hoses from the ports at the back of the machine (ensure that you keep a rag nearby to clean leaks).
Step 3. Go to the front of your machine, then pull the detergent tray out. Press the little button in the tray to release it from the housing.
Step 4. With a Philips screwdriver, loosen the two nuts next to the dispenser’s opening on the control panel.
Step 5. From the back of the machine, loosen the Philips screws holding the top panel. Slide the panel backwards about an inch or so, then lift it off the cabinet.
Step 6. If your machine has one, loosen the screws holding the vibration dampening block to the top of the machine. Lift the block off carefully and set it aside.
Step 7. Loosen the screw securing the drain hose retainer to the back of the machine. Pull the retainer off.
Step 8. Unplug the grounding wire and power cord wire harness at the back of the cabinet. Release the power cord’s wire retainer from the back of the cabinet using needle-nosed pliers.
Step 9. Loosen the nuts securing the rail to the top of the rear cover. Lift the rail off the machine and set it aside.
Step 10. Take out the screws securing the rear cover to the machine. Carefully lift the panel off the machine and support it against the side of the cabinet (the drain hose is still attached to the rear panel at this point).
Step 11. Disconnect the wires attached to the water inlet valve (make sure to take note where each plug goes).
Step 12. Take out the Philips screws holding the dispenser and valve assembly to the cabinet. Pull the dispenser assembly out of place.
Step 13. Use your Philips screwdriver to loosen the screw-clamp holding the outlet hose to the dispenser. Detach the hose from the dispenser assembly.
Step 14. Release the retaining clamp holding the other end of the outlet hose to the top of the tub. Detach the hose from the tub, then pull it out of the cabinet.
Step 15. Carefully inspect the outlet hose for puncture marks or other signs of damage. If you notice any damage to the hose, replace it.
Step 16. Once you have confirmed that the outlet hose is in good condition, reconnect it to the dispenser housing, then tighten the screw-clamp.
Step 17. Attach the other end of the hose to the tub, then secure it using the retaining clamp.
Step 18. Push the dispenser assembly back into place, then tighten the screws at the top to secure it to the cabinet.
Step 19. Plug each wire connector into its appropriate terminal on the water inlet valve. Apply the screws next to the dispenser’s opening on the control panel.
Step 20. Push the soap tray back into the dispenser opening. Remount the rear panel on the machine, then use your Philips screwdriver to apply the nuts.
Step 21. Slide the retainer onto the drain hose, then apply the Philips screw. Mount the rail on the rear panel, then tighten the Philips screws.
Step 22. Push the wire retainer into the slot on the support rail. Plug the power cord’s grounding wire and wire harness back in.
Step 23. Place the vibration block on the machine, then tighten the nuts. Place the top cover on the cabinet, then apply the Philips screws at the back.
Step 24. Connect the COLD and HOT water inlet hoses to the appropriate ports at the back of the cabinet.
Step 25. Reconnect your appliance to the electrical outlet, then fully open the water faucets. Try turning the machine on to see if your AEG washing is leaking.
Note: Some of the steps in the section above may be a bit different depending on the model of your washing machine.
4. AEG Washing Machine Is Leaking — Punctured Door Boot Seal
If your AEG washing machine is leaking from the from the door, it is the result of a damaged door boot seal. Follow the steps below to replace this part…
Step 1. Disconnect your appliance from the power outlet before starting this procedure in order to avoid electrocution.
Step 2. Go to the back of your appliance, then take out the Philips screws holding the top cover. Pull the cover backwards about an inch or so, then lift it off.
Step 3. From the front of the machine, pull the soap tray out, then release it from the housing by pressing the little button inside.
Step 4. Loosen the screws at the top of the control panel. Take out the nuts next to the dispenser’s opening on the control panel.
Step 5. Using a flat-blade screwdriver if needed, pry the control panel off the mounting bracket at the front of the machine. Unplug the user interface wire connector from the panel and set it aside.
Step 6. Open the door of your machine. Wedge a flat-blade screwdriver underneath the retaining wire around the seal. Work the screwdriver around until the wire pops off.
Step 7. Tip the machine backwards carefully, then place a support underneath it (get someone to help you if needed).
Step 8. Using your Philips screwdriver, take out the nuts at the bottom of the front panel. Take the support out and lower the machine onto the floor.
Step 9. Loosen the Philips screws at the top of the front panel. Lift the front panel off the machine carefully. Disconnect the door lock wire connector at the back of the front panel, then set the panel aside.
Step 10. Detach the tubes from the ports on the door boot seal. Pry the light assembly off the port at the top of the door seal (your washer’s model may not have this).
Step 11. Using a 13mm socket wrench, take out the bolts securing the lower and upper weights to the drum. Lift each weight off the drum carefully.
Step 12. Wedge a flat-blade screwdriver underneath the inner retaining band around the door boot seal. Work the screwdriver around until the wire pops off.
Step 13. Pry the door boot seal off the drum opening and discard it. Prepare your new door seal for installation by unpacking it.
Step 14. Carefully fit the new door boot seal around the drum opening (ensure that the ports on the new seal are properly lined up with the tub).
Step 15. Use a needle-nosed pliers or a flat-blade screwdriver to fit the inner retaining wire around the new door seal.
Step 16. Lift each of the front weights, then carefully mount them on the drum. Secure each weight by applying the bolts with your socket wrench.
Step 17. Connect each tube to its appropriate port on the new door seal. Push the light assembly into the port on the seal.
Step 18. Lift the front panel carefully, then reconnect the door switch wire harness. Mount the panel on the cabinet, then use your Philips screwdriver to apply the screws at the top.
Step 19. Carefully tilt the appliance backwards, then place something underneath to support it. Tighten the Philips screws beneath the front panel.
Step 20. Set your washing machine back onto its feet, then open the door. Fit the new door seal around the lip of the front panel.
Step 21. With your flat-blade screwdriver, fit the second retaining wire around the door seal.
Step 22. Reconnect the user interface wire connector to the control panel. Mount the panel on the bracket at the front of the machine, then use your Philips screwdriver to apply the nuts at the top.
Step 23. Tighten the two screws next to the dispenser’s opening on the control panel. Push the detergent tray into the dispenser.
Step 24. Mount the top panel on the machine, then push it forwards. Secure the cover by tightening the Philips screws at the back.
Step 25. Plug your appliance into the power outlet. To find out if your AEG washing machine is leaking, try running a cycle.
