It’s quite irritating when your AEG washing machine smells. If you have this issue, you’ve come to the right place; this detailed guide provides steps on how to handle the situation…
Table of Contents
AEG Washing Machine Smells Bad — How To Fix
If your AEG washing machine smells bad, the following are issues to look for…
1. AEG Washing Machine Smells Bad — Mould In Drum
If the drum in your AEG washing machine smells bad, it is most likely due to dirt and mould build-up. Follow the steps below to clean your washing machine’s drum…
Step 1. Take out all the clothes in your washing machine. Pour about two cups of white vinegar into the drum (vinegar helps kill mould).
Step 2. Turn your washing machine on, then set a normal wash cycle with the highest water temperature. Press the Start button to begin the cycle.
Step 3. Once the cycle is complete, open the door of the machine. Dip a rag in some bleach (or vinegar), then clean the door boot seal. Leave the door of the appliance open (this will help the drum air out.
2. AEG Washing Machine Smells Bad — Build-Up In Dispenser
If your AEG washing machine smells bad, the second thing to do is clean the dispenser assembly. Follow the steps below to do this…
Step 1. Pull the soap tray out of the dispenser, then press the little button inside to release it from the housing.
Step 2. Take the tray to a sink, then use a soft brush to clean out detergent residue. Once the tray is clean, set it aside.
Step 3. Disconnect your appliance from the power outlet, then turn the water faucets off.
Step 4. Use a Philips screwdriver to loosen the nuts securing the top panel to the cabinet. Pull the cover backwards, then lift it off the cabinet.
Step 5. Disconnect the COLD and HOT water supply hoses from the ports at the back of the machine (keep a rag nearby to clean any leaks).
Step 6. Loosen the nut securing the retainer to the drain hose at the back of the appliance. Slide the retainer off the hose and set it aside.
Step 7. Disconnect the power cord’s wire plug at the back of the cabinet, then unplug the grounding wire.
Step 8. Using needle-nosed pliers, release the power cord wire retainer from the slot on the rear cover.
Step 9. Loosen the screws securing the support rail to the rear access panel. Lift the rail off the panel and set it aside.
Step 10. Use your Philips screwdriver to take out the screws holding the rear access panel to the cabinet. Lift the rear panel off the machine carefully, then support it against the cabinet.
Step 11. Note the positioning of the wires attached to the water inlet valve, then disconnect each one.
Step 12. Loosen the screws securing the inlet valve to the dispenser assembly. Pull the valve off and set it aside.
Step 13. Use your screwdriver to loosen the screw-clamp holding the outlet hose to the dispenser assembly. Pull the hose off the dispenser.
Step 14. Take out the screws on the control panel securing the dispenser assembly. Loosen the screws on the support rail securing the dispenser. Pull the dispenser backwards a bit.
Step 15. Reach into the cabinet, then use a pair of pliers to release the retaining clamp securing the vent hose to the dispenser. Pull the hose off the dispenser.
Step 16. Pull the dispenser assembly out of the cabinet carefully. Take the dispenser to a sink. Using a flat-blade screwdriver if needed, release the retaining tabs securing the two halves of the dispenser.
Step 17. Clean out any detergent and mould that may have built up in the dispenser. Once the dispenser assembly is clean, snap the two halves back together.
Step 18. Attach the water inlet valve to the dispenser housing, then apply the Philips screws to secure it.
Step 19. Push the dispenser and inlet valve assembly into place in the cabinet. Reach in and reconnect the vent hose to the port on the dispenser. Move the retaining clamp into place to secure the hose.
Step 20. Go to the front of the machine, then tighten the two nuts next to the dispenser’s opening. Push the detergent tray into the dispenser.
Step 21. Go to the back of the appliance, then connect the outlet hose to the port at the bottom of the dispenser. Tighten the screw-clamp to secure the hose. Apply the nuts on the support rail to secure the dispenser.
Step 22. Lift the rear access panel, then mount it on the cabinet. Secure the rear panel by tightening the screws.
Step 23. Mount the support rail on the rear panel, then apply the Philips screws to secure it. Snap the power cord wire retainer into the support rail.
Step 24. Reconnect the power cord’s wire connector and grounding wire. Push the retainer onto the drain hose, then apply the Philips screw.
Step 25. Plug each connector into its appropriate terminal on the water inlet valve. Mount the top cover on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.
Step 26. Reconnect the HOT and COLD water supply hoses to the ports at the back of the machine (ensure that each hose is properly attached so water doesn’t leak).
Step 27. Plug your appliance into the power outlet, then turn the water supply faucets on. Run a wash cycle to ensure that everything works properly.
AEG Washing Machine Smells Burnt — Solved
If your AEG washing machine smells like it’s burning, the following are causes to look for…
1. AEG Washing Machine Smells Burnt — Worn-Out Belt
If your AEG washing machine smells burnt, the first thing to do is check if the drive belt is worn out and damaged. Follow the steps below to do this…
Front Loaders
Take the following steps to check the drive belt in your front loader AEG washing machine…
Step 1. In order to avoid any leaks or chances of electrocution, ensure that you unplug your washing machine from the power outlet and turn the water taps off before starting this procedure.
Step 2. Go to the back of the machine, then use a pair of pliers to disconnect the COLD and HOT water supply hoses (some water may spill, so keep a rag nearby).
Step 3. Use a Philips screwdriver to loosen the nuts holding the top panel to the appliance. Pull the cover backwards about an inch or so, then lift it off the machine.
Step 4. Use your screwdriver to take out the bolt holding the drain hose retainer at the back of the machine. Pull the retainer off.
Step 5. Unplug the power cord’s grounding wire at the back of the cabinet. Disconnect the power cord’ wire connector.
Step 6. With a pair of needle-nosed pliers, release the power cord wire retainer from the support rail on the rear panel.
Step 7. Loosen the screws securing the rail to the rear access cover. Lift the rail off the machine. Take out the bolts holding the rear panel to the cabinet. Lift the panel off the machine, then support it against the cabinet.
Step 8. Inspect the drive belt to see if it is worn out or smells burnt. If the belt is damaged in any way, slide it off the pulleys and replace it.
Step 9. Once you are sure that the drive belt is in good condition, remount the rear panel onto the cabinet, then tighten the Philips screws.
Step 10. Push the retainer onto the drain hose and apply the nut. Mount the support rail on the rear panel, then tighten the screws.
Step 11. Plug the power cord’s grounding wire back in. Reconnect the power cord wire connector, then snap the wire retainer into the slot on the support rail.
Step 12. Mount the top panel on the appliance, then push it into place. Secure the panel by applying the Philips screws.
Step 13. Reattach the HOT and COLD water supply hoses to the corresponding ports at the back of the cabinet.
Step 14. Plug your washer into the power outlet, then open the water faucets. Try running a wash cycle and see if your AEG washing machine smells still.
Dryers
Inspect the drive belt of an AEG dryer by following the steps below…
Step 1. Unplug your appliance from the power outlet before starting this procedure in order to prevent any chances of electrocution.
Step 2. With a Philips screwdriver, go to the back of the appliance, then loosen the screws securing the top cover. Pull the cover backwards about an inch or so, then lift it off.
Step 3. Take out the screws at the top of the control panel. Using a flat-blade screwdriver if needed, pry the control panel off the mounting bracket at the front of the machine.
Step 4. Unplug the interface wire connector from the control panel, then set the panel aside. Open the door of your machine.
Step 5. Loosen the screws on the front panel securing the lint filter housing. With someone assisting you, carefully tilt your washing machine backwards and support it.
Step 6. Use your screwdriver to take out the nuts at the bottom of the front panel. Lower the machine onto the floor.
Step 7. Loosen the screws at the top of the front panel. Lift the front panel off the cabinet, then unplug the door switch wire connector at the back.
Step 8. Unplug the user interface and drum light connectors from the main control board mounted on the drum (ensure that you take note of where each plug goes).
Step 9. With your screwdriver, loosen the screws on the front bulkhead securing the control board’s support bracket.
Step 10. Move the control board’s support bracket out of place, then support it. With your Philip screwdriver, loosen the nuts holding the front bulkhead to the drum.
Step 11. Lift the front bulkhead off the drum carefully and set it aside. Reach underneath the drum and push the idler pulley inwards.
Step 12. Unhook the drive belt from motor and idler pulleys (if still intact). Slide the belt off the drum. Carefully inspect the drive belt. If the belt smells burnt or looks worn out and damaged, replace it.
Step 13. Once you are sure that the drive belt is in good condition, loop it around the drum. Reach under the drum, then hook the belt onto the motor and idler pulleys.
Step 14. To ensure that the drive belt is properly aligned, rotate the drum by hand. Once the belt is in place, mount the front bulkhead on the drum.
Step 15. Secure the front bulkhead by applying the Philips screws. Place the control board’s support bracket against the front bulkhead. Secure the bracket by applying the screws.
Step 16. Plug the user interface and drum light connectors into the appropriate terminals on the main control board.
Step 17. Lift the front panel. Plug the door switch connector into the front panel. Carefully mount the panel onto the bulkhead, then apply the Philips screws at the top.
Step 18. Tilt the dryer backwards, then support it. Tighten the screws under the panel, then lower the machine onto the floor.
Step 19. Open the door, then apply the screws on the front panel to secure the lint filter housing.
Step 20. Plug the interface wire connector into the control panel. Snap the control panel onto the front of the cabinet, then use your Philips screwdriver to tighten the nuts at the top.
Step 21. Place the top cover on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.
Step 22. Plug your dryer into the electrical outlet. Try running a cycle to see if your AEG washing machine smells burnt.
2. AEG Washing Machine Smells Burnt — Damaged Motor Control Board (Front Loaders)
If your front loader AEG washing machine smells burnt, you should check the motor control board to ensure it isn’t damaged. Follow the steps below to do this…
Step 1. In order to avoid electrocution and leakage, ensure that you disconnect your washing machine from the outlet and shut the water supply taps before starting this repair.
Step 2. Go to the back of your washing machine, then use pliers to disconnect the HOT and COLD water supply hoses from the ports (ensure that you keep a towel nearby in case water spills).
Step 3. Use a Philips screwdriver to remove the nuts holding the top cover to the cabinet. Pull the cover backwards about an inch or so, then lift it off.
Step 4. Take out the nut securing the retainer to the drain hose. Pull the retainer off and set it aside.
Step 5. Disconnect the power cord’s grounding wire at the back of the cabinet. Unplug the power cord wire connector.
Step 6. Use needle-nosed pliers to release the power cord wire retainer from the slot on the support rail.
Step 7. Take out the screws holding the support rail to the rear cover. Lift the rail off the cabinet and set it aside.
Step 8. Remove the Philips screws holding the rear access panel to the cabinet. Carefully lift the panel off the appliance, then support it against the cabinet.
Step 9. Take out the nuts securing the motor control board at the lower side of the cabinet using a Philips screwdriver. Pull the board out of place.
Step 10. Pry the cover off the motor control board, then unplug each wire connector (ensure that you take note of where the plugs go).
Step 11. Use your needle-nosed pliers to release the retainer securing the retainer to the control board housing.
Step 12. Inspect the terminals on the control board for burn marks or signs of damage. If you notice any damage to the board, replace it immediately.
Step 13. Once you’ve acquired your new motor control board, snap the wire retainer in. Plug each connector into its appropriate terminal on the new board.
Step 14. Snap the cover onto the motor control board. Install the new board in the cabinet, then apply the Philips screws to secure it.
Step 15. With the new board in place, lift the rear access panel, then carefully snap it onto the cabinet. Apply the Philips screws to secure the panel.
Step 16. Mount the support rail on the rear access panel, then apply the screws. Snap the wire retainer into the support rail.
Step 17. Plug the grounding wire and power cored wire retainer back in. Push the retainer onto the drain hose, then secure it with the screw.
Step 18. Mount the top panel on the machine, then push it into place. Secure the panel by applying the Philips screws at the back.
Step 20. Connect the COLD and HOT water supply hoses to the appropriate ports on the machine (ensure that each hose is properly attached so water doesn’t leak).
Step 21. Plug your washer back into the electrical outlet, then open the water faucets. Try running a wash cycle to see if your AEG washing machine smells.
3. AEG Washing Machine Smells Burnt — Burnt Main Control Board
You need to inspect the main control board for damage if your AEG washing smells burnt. Follow the steps below to do this…
Front Loaders
Take the following steps to inspect the main control board in your front loader AEG washing machine…
Step 1. Avoid any chances of electrocution by unplugging your appliance from the power outlet before starting this procedure.
Step 2. From the back of the cabinet, use a Philips screwdriver to remove the nuts securing the top cover. Pull the cover back, then lift it off.
Step 3. Using a flat-blade screwdriver if needed, pry the cover off the main control board mounted on the cabinet.
Step 4. Note the positioning of the plugs attached to the control board, then unplug each one. Use a pair of needle-nosed pliers to release the wire harness retainer from the housing.
Step 5. Loosen the screws securing the control board to the side of the cabinet. Pull the board out of the machine.
Step 6. Carefully inspect the control board for burn marks or other signs of damage. Replace the board at once if it’s damaged.
Step 7. Mount the board on the cabinet, then tighten the screws to secure it. Snap the wire retainer into the slot, then plug each connector to its corresponding terminal.
Step 8. Place the top panel on the cabinet, then push it into place. Secure the panel by applying the Philips screws.
Step 9. Reconnect your appliance to the electrical outlet, then try running a wash cycle to see if your AEG washing machine smells burnt.
Dryers
Inspect and replace the main control board in your AEG dryer by taking the following steps…
Step 1. Prevent any chances of electrocution by unplugging your washer from the power outlet before starting.
Step 2. Take out the screws at the back of the cabinet holding the top panel. Pull the panel back a bit, then lift it off.
Step 3. Disconnect each plug attached to the main control board at the top of the drum (take note of where the plugs go).
Step 4. If needed, use needle-nosed pliers to help release the wire retainers from the control board housing.
Step 5. Loosen the screws holding the control board to the support bracket. Lift the board off. Inspect the board closely for signs of damage such as burn marks. Replace the board if needed.
Step 6. Once you are sure that the control board is in good condition, mount it on the support bracket and tighten the screws.
Step 7. Snap the wire retainers into the slots on the control board housing. Plug each connector into its appropriate terminal on the board.
Step 8. Mount the top cover on the cabinet, then slide it into place. Apply the screws at the back of the cabinet.
Step 9. Plug your appliance back into the power outlet. Run a cycle to find out if your AEG washing machine smells burnt.
4. AEG Washing Machine Smells Burnt — Burning Motor
If your AEG washing machine smells burnt, the final thing to do is ensure the motor isn’t burnt. Follow the steps below to do this…
Front Loaders
Check your front loader AEG washing machine’s drive motor by following the steps below…
Step 1. In order to avoid electrocution, make sure to unplug your appliance from the outlet before starting this repair.
Step 2. Turn the HOT and COLD water faucets off. Using a pair of pliers if needed, disconnect the water hoses from the ports at the back of the machine (ensure that you keep a rag nearby in case water spills).
Step 3. Use a Philips screwdriver to take out the nuts at the back of the machine holding the top cover. Pull the cover backwards about an inch or so, then lift it off.
Step 4. Loosen the nut holding the drain hose retainer to the back of the cabinet. Pull the retainer off the hose and set it aside.
Step 5. Disconnect the power cord’s grounding wire at the back of the appliance. Unplug the power cord connector.
Step 6. Using a pair of needle-nosed pliers if needed, release the wire retainer from the support rail on the rear access panel.
Step 7. Take out the screws holding the support rail to the cabinet. Lift the rail off the and set it aside.
Step 8. Remove the screws holding the rear access panel to the cabinet. Carefully lift the panel off the machine, then set it aside (the drain hose will still be attached to the panel).
Step 9. Inspect the drive motor underneath the tub carefully and see if it smells burnt. If the motor is hot, wait for it to cool down before moving on.
Step 10. Once the motor has cooled down, unhook the drive belt from the motor pulley and drive pulley.
Step 11. Reach under the tub, then carefully unplug the wire harness from the drive motor. Use a 5/16 inch nut-driver to take out the bolts holding the motor to the bottom of the tub. Carefully pull the motor out of the cabinet.
Step 12. If needed, use a pair of needle-nosed pliers to release the wire harness retainer from the motor assembly. Discard the old drive motor, then take the new one out of its packaging.
Step 13. Snap the retainer into the motor housing, then plug the wire harness in. Mount the motor under the tub, then apply the nuts to secure it.
Step 14. Loop the belt around the motor and drive pulleys (make sure the grooved side is facing inwards).
Step 15. Snap the rear access panel onto the cabinet, then apply the nuts using your Philips screwdriver.
Step 16. Push the retainer onto the drain hose at the back of the machine. Apply the screw to secure the retainer.
Step 17. Mount the support rail on the rear panel, then apply the bolts to secure it. Snap the power cord’s wire retainer into the slot on the support rail.
Step 18. Plug the power cord’s grounding wire back in. Reconnect the power cord connector.
Step 19. Place the top panel back on the cabinet, then push it forwards. Secure the panel by applying the Philips screws.
Step 20. Connect the COLD and HOT water inlet hoses to their corresponding ports (in order to prevent leakage, ensure that each hose is properly attached).
Step 21. Plug your washing machine back into the electrical outlet, then turn the water faucets back on. Run a wash cycle to see if your AEG washing machine smells burnt.
Dryers
Check if the drive motor in your AEG washing machine is burnt by following the steps below…
Step 1. In order to prevent any chances of electrocution, make sure to disconnect your machine from the power outlet before starting.
Step 2. Go to the back of the cabinet, then loosen the nuts securing the top panel using a Philips screwdriver. Slide the panel backwards a bit, then lift it off.
Step 3. Loosen the screws at the top of the control panel. Pry the panel off the mounting bracket at the front of the machine (use a flat-blade screwdriver if needed).
Step 4. Disconnect the user interface connector from the control panel, then set the panel aside.
Step 5. Unplug the drum light and user interface connectors from the control board at the top of the drum (ensure that you take note of where each plug goes).
Step 6. Open the door of your appliance. Loosen the screws on the front panel securing the lint filter housing.
Step 7. Tilt your washing machine backwards, then place a support underneath (get someone to assist you if needed).
Step 8. Loosen the screws under the front panel. Lower the machine onto the floor, then remove the screws at the top of the front panel.
Step 9. Carefully lift the entire front panel off the cabinet. Unplug the door switch connector behind the front panel, then set the panel aside.
Step 10. Take out the nuts securing the control board’s mounting bracket to the front bulkhead. Carefully lift the bracket out of place and support it.
Step 11. Remove the screws holding the bulkhead to the front of the machine. Lift the bulkhead off carefully and set it aside.
Step 12. Reach underneath the drum carefully, then release the tension on the drive belt by pushing the idler pulley out of place.
Step 13. Unhook the belt from the motor and idler pulleys. Lift the drum and drive belt out of the cabinet carefully, then set them aside.
Step 14. Inspect the drive motor for burn marks and see if you can smell anything. If you notice a burning smell coming from the motor, you’ll need to take it out and replace it.
Step 15. Unplug the wire connector from the motor assembly. Secure the motor shaft with pliers, then use a 7/8 inch socket wrench to loosen the blower wheel.
Step 16. Using a flat-blade screwdriver if needed, pry off the two retaining clips securing the motor to the cabinet. Pull the motor out of place, then discard it.
Step 17. Prepare your new motor assembly for installation by unpacking it. Mount the new motor in the cabinet, then snap the rear and front retaining clamps on to secure it.
Step 18. Plug the connector into the new motor. Secure the motor’s shaft, then lock the blower wheel in place using your socket wrench.
Step 19. With the new drive motor in place, lift the tub and drive belt, then carefully guide them back into the cabinet.
Step 20. Reach under the drum and loop the belt back onto the pulleys in a zig-zag pattern. Turn the drum by hand to ensure that the belt sits properly.
Step 21. Mount the bulkhead onto the drum, then secure it by tightening the Philips screws. Place the control board’s bracket against the front bulkhead. Apply the screws to secure the bracket.
Step 22. Lift the front panel carefully, then plug the door switch connector back in. Snap the panel onto the front of the machine. Apply the Philips screws at the top of the panel.
Step 23. Open the door, then secure the lint filter housing by tightening the screws on the front panel.
Step 24. Tilt the appliance backwards carefully, then support it. Apply the bolts underneath the front panel. Lower the dryer to the floor.
Step 25. Plug the interface and drum light connectors into their appropriate terminals on the main control board.
Step 26. Plug the other end of the user interface connector into the control panel. Snap the panel onto the front of the machine, then use your Philips screwdriver to apply the nuts at the top.
Step 27. Place the top cover on the machine, then push it forwards. Apply the nuts at the back to secure the panel.
Step 28. Reconnect the dryer to the power outlet. Try running a cycle to find out if your AEG washing machine smells.
Note: Some of the steps in the section above will be slightly different depending on the model of your washing machine.
