AEG Washing Machine Error Codes [Issues & Proven Solutions]

AEG washing machine error codes are quite frustrating when you don’t know how to deal with them. This detailed article explains the meanings of various AEG washing machine error codes, and provides simple steps to fix them…

AEG Washing Machine Error Code C1 — How To Fix

The C1 AEG washing machine error code indicates that the machine isn’t filling with water like it’s supposed to. When you get this error, the first thing to do is ensure that the water faucets are turned on, and the inlet hoses aren’t bent or kinked.

If the error code still isn’t cleared after this, the next thing to check is the water inlet valve. Follow the steps below to test this part…

Step 1. In order to prevent electrocution and leakage, ensure that you disconnect your appliance from the power outlet and turn the water taps off before starting this procedure.

Step 2. Go to the back of the cabinet, then disconnect the water inlet hoses from the ports (it is advised that you keep a towel nearby to clean any leaks).

Step 3. Using a Philips screwdriver, take out the bolts holding the top panel to the cabinet. Slide the panel backwards a few inches and lift it off the cabinet.

Step 4. Use your screwdriver to take out the nuts holding the vibration dampening block to the top of the machine. Lift the block off carefully and set it aside.

Step 5. Disconnect the power cord’s wire harness and grounding wire at the back of the cabinet. Release the power cord’s wire retainer from the support rail using needle-nosed pliers.

Step 6. Loosen the bolts holding the support rail to the top of the rear panel. Lift the rail off the machine and set it aside.

Step 7. Loosen the screw securing the retainer to the drain hose. Pull the retainer off and set it aside.

Step 8. Use your Philips screwdriver to take out the nuts holding the rear panel to the cabinet. Lift the panel off the machine, then set it aside (please note that the drain hose will still be attached to the panel).

Step 9. Unplug the wire connectors from the water inlet valve attached to the dispenser (ensure that you note where each connector goes).

Step 10. With your screwdriver, loosen the bolts holding the inlet valve to the dispenser assembly. Pull the valve off the dispenser.

Step 11. Get a digital multimeter, then turn the control knob to the lowest setting for ohms of resistance.

Step 12. Push the meter’s probes into each of the valve’s terminals. For a working valve, look for a reading between 500 and 1600 ohms. If the reading is much higher or lower than these numbers, the valve is damaged and needs to be replaced.

Step 13. If the valve’s readings came out all right, remount it on the dispenser, then apply the Philips screws to secure it.

Step 14. Plug each wire connector into its appropriate terminal on the water inlet valve. Lift the rear panel, then remount it on the cabinet. Apply the Philips screws to secure the rear panel.

Step 15. Mount the support rail on the rear panel, then tighten then screws. Slide the retainer onto the drain hose, then apply the Philips screw.

Step 16. Plug the power cord’s wire connector and grounding wire back in. Snap the wire retainer into the little slot on the support rail.

Step 17. Place the vibration dampening block on the cabinet, then apply the Philips screws. Mount the top panel on the cabinet and push it forwards. Apply the bolts at the back of the cabinet.

Step 18. Reconnect the HOT and COLD water hoses to the corresponding ports. Plug your appliance back into the electrical outlet, then turn the water taps on. Ensure that the AEG washing machine error code is gone by running a wash cycle.

Note: For more detailed steps on how to fix a washing machine that won’t fill, read this article: AEG Washing Machine Is Not Filling.

AEG Washing Machine Error Code C2 — Solved

The C2 AEG washing machine error code indicates that your machine isn’t draining properly. If you get this error code, the first thing to do is ensure that the pump filter is clean. If your washer still doesn’t drain after cleaning the filter, you’ll need to test the drain pump with a digital multimeter. Follow the steps below to do this…

Step 1. In order to avoid electrocution, ensure that you disconnect your washing machine from the power outlet before starting the repair.

Step 2. Pull the washer forwards a bit to gain access to the rear. With a Philips screwdriver, take out the nuts holding the top cover to the cabinet. Pull the panel backwards about an inch or so, then lift it off the machine.

Step 3. Go to the front of the machine, then pull the detergent tray out. Release the tray by pressing the little tab inside. Take out the screws next to the dispenser’s opening on the control panel.

Step 4. Loosen the nuts at the top of the control panel using a Philips screwdriver. Pry the control panel off the mounting bracket at the front of the machine. Place the panel on the cabinet.

Step 5. Open your washing machine’s door. Use a flat-blade screwdriver or needle-nosed pliers to carefully pry off the retaining wire securing the door boot seal (take care not to puncture the seal).

Step 6. Pry the door boot seal off the lip of the front panel. Get someone to help you tip your washing machine backwards a bit and support it.

Step 7. With your Philips screwdriver, take out the nuts at the bottom of the front panel. Set your machine back onto its feet.

Step 8. Loosen the nuts at the top of the front panel. Lift the panel off the cabinet carefully. Reach behind the front panel, then unplug the door lock wire connector. Set the front panel aside.

Step 9. Disconnect the wire harness from the drain pump assembly at the bottom of the tub.

See also  Washing Machine Vibrates Too Much [Easy Fix]

Step 10. With a pair of pliers, squeeze the spring clamps holding the outlet hose and sump hose to the drain pump. Move the spring clamps out of place.

Step 11. Disconnect each hose from the drain pump (some water may spill, so ensure that you keep a rag nearby to clean any leaks).

Step 12. With your screwdriver, take out the nuts holding the drain pump to the cabinet. Pull the pump assembly out of the machine.

Step 13. Get a digital multimeter, then turn the control dial to the ohms setting. Push the probes of the meter into the terminals on the drain pump. A working pump should give a reading of roughly 20 ohms.

Step 14. If the readings are significantly lower or higher than the number indicated above, the pump is damaged and needs to be replaced.

Step 15. Once you are sure that the pump is in good condition, install it in the cabinet, then apply the Philips screws to secure it.

Step 16. Plug the wire harness back into the drain pump. Reconnect the hoses to their corresponding ports on the pump. Secure the hoses by sliding the spring clamps into place.

Step 17. Lift the front panel carefully, then reconnect the door switch wire connector. Mount the front panel on the cabinet, then apply the Philips screws at the top.

Step 18. Tip the machine backwards carefully, then support it. Apply the nuts at the bottom of the front panel. Set your washing machine back on its feet.

Step 19. Snap the control panel onto the front of the machine, then secure it by applying the Philips screws at the top. Tighten the screws on the control panel next to the dispenser’s opening.

Step 20. Open the door of the machine, then fit the door boot seal around the lip of the front panel. with a flat-blade screwdriver, carefully fit the retaining band around the door seal.

Step 21. Push the soap tray back into the dispenser. Mount the top cover on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.

Step 22. Plug your washing machine into the power outlet, then try running a wash cycle to ensure that the error code is gone.

AEG Washing Machine Error Code C3 — Quick Fix

This AEG washing machine error code indicates that a leak has been detected. This is most likely caused by a loose hose inside the machine. Follow the steps below to fix this issue…

Step 1. In order to avoid any chances of electrical damage, ensure that your appliance is disconnected from the power outlet before starting this repair.

Step 2. Go to the back of the appliance, then use a Philips screwdriver to take out the nuts holding the top cover. Pull the panel backwards about an inch or so, then lift it off.

Step 3. Slide the detergent tray out, then press the little button inside to release it from the dispenser.

Step 4. Loosen the two nuts on the control panel next to the dispenser’s opening. Take out the bolts at the top of the control panel. Pry the panel off the front of the machine, then place it on top of the cabinet.

Step 5. Open the door of your washing machine. Wedge a flat-blade screwdriver underneath the retaining band around the door seal. Carefully work the screwdriver around until the wire pops off.

Step 6. Carefully pry the door seal off the lip of the front panel. Get someone to help you tilt your washing machine backwards a bit and support it. Using your Philips screwdriver, take out the nuts underneath the front panel.

Step 7. Lower the machine back onto the floor. Take out the Philips screws at the top of the front panel. Lift the front panel off the machine.

Step 8. Reach behind the front panel, then unplug the door switch wire connector. Set the front panel aside.

Step 9. Carefully inspect the hoses attached to the drain pump and ensure that they are properly connected. If any hose feels loose, use pliers to move the spring clamps properly into place.

Step 10. Once you are sure that the hoses are properly secured, lift the front panel, then plug the door switch wire connector in.

Step 11. Mount the front panel on the cabinet, then use your screwdriver to apply the bolts at the top.

Step 12. Tip the appliance backwards carefully and support it. Tighten the bolts at the bottom of the front panel.

Step 13. Lower your washing machine onto the floor. Open the door of the machine, then fit the door gasket around the lip of the front panel.

Step 14. Snap the control panel onto the mounting bracket at the front of the cabinet. Secure the panel by applying the Philips screws next to the dispenser’s opening.

Step 15. Apply the nuts at the top of the control panel, then push the soap tray into the dispenser.

Step 16. Place the top cover on the cabinet, then push it forwards. Secure the panel by applying the Philips screws at the back.

Step 17. Plug your washing machine back into the electrical outlet. Try running a cycle to ensure that the AEG washing machine error code is gone.

AEG Washing Machine Error Code C7 — How To Fix

This AEG washing machine error code indicates that the water isn’t heating. This issue is caused by a damaged heating element. Follow the steps below to replace this part…

Front Loaders

Do the following to replace a damaged heating element in your front loader AEG washing machine…

Step 1. Prevent any chances of electrical damage by disconnecting your washing machine from the power outlet before starting this repair.

Step 2. Go to the back of the cabinet, then use a Philips screwdriver to loosen the nuts holding the rear access panel.

Step 3. Lift the rear access panel off the cabinet and set it aside. Unplug the wire connectors from the heating element at the bottom of the tub (make sure to note where each plug goes).

Step 4. With a 10mm socket wrench, loosen the nut holding the heating element to the tub. Pry the element out of the housing using a flat-blade screwdriver, then discard it.

Step 5. Prepare the new heating element for installation by unpacking it. Push the new element into the housing at the bottom of the tub, then secure it by applying the 10mm bolt.

See also  Whirlpool Washing Machine Motor [Issues, Proven Solutions & Guide]

Step 6. Plug each wire connector into its appropriate terminal on the new heating element.

Step 7. Carefully remount the rear access panel onto the cabinet, then apply the Philips screws to secure it.

Step 8. Plug your washing machine back into the electrical outlet. To ensure that the AEG washing machine error code is gone, try running a wash cycle.

Dryers

The steps below show how to replace a damaged heating element in your AEG dryer…

Step 1. In order to prevent any chances of electrocution, ensure that you disconnect your machine from the power outlet before starting this repair.

Step 2. From the back of the machine, use a Philips screwdriver to take out the bolts holding the top cover. Slide the panel backwards about a few inches, then lift it off the machine.

Step 3. Use your screwdriver to take out the bolts at the top of the front panel. Pry the panel off the mounting bracket, then unplug the wire harness. Set the control panel aside.

Step 4. Open the door of your dryer, then use your screwdriver to take out the nuts on the front panel securing the lint filter housing.

Step 5. With someone assisting you, tip the appliance backwards carefully and support it. Loosen the nuts at the bottom of the front panel.

Step 6. Lower the machine onto the floor. Take out the Philips screws at the top of the front panel. Lift the panel off the machine carefully. Reach behind the front panel, then unplug the door lock wire connector.

Step 7. Set the front panel aside. Unplug the drum light and door switch wire connectors from the main control board mounted on the drum.

Step 8. Use your screwdriver to loosen the nuts holding the control board’s support bracket to the front bulkhead. Detach the bracket from the bulkhead and support it.

Step 9. Take out the screws holding the front bulkhead to the drum. Lift the bulkhead off the drum carefully, then support it against the cabinet.

Step 10. Reach underneath the drum carefully, then push the idler pulley inwards (this release the tension on the drive belt).

Step 11. Unhook the drive belt from the idler pulley and motor pulley. Lift the drum and drive belt out of the cabinet carefully, then set them aside.

Step 12. With your Philips screwdriver, loosen the nuts holding the heating element element housing to the base. Take out the nuts securing the element to the air duct.

Step 13. Pull the heating element out of place. Loosen the screws holding the thermal fuse and high limit thermostat to the heating element housing. Pull the thermostat and fuse off, then set them aside.

Step 14. Unplug the each wire connector from the heating element (note where each wire connector goes).

Step 15. Take out the screws holding the support base to the heating element. Detach the base and set it aside. Discard the old heating element, then prepare the new one for installation by unpacking it.

Step 16. Attach the support bracket to the new heating element, then apply the Philips screws to secure it.

Step 17. Plug each wire connector into its appropriate terminal on the new heating element. Place the thermostat and thermal fuse on the new heating element, then apply the nuts.

Step 18. Mount the new heating element on the air duct, then apply the screws. Apply the nuts to secure the heating element to the mounting base.

Step 19. Lift the drum and drive belt, then carefully guide them into the cabinet. Reach underneath the drum, then hook the belt onto the motor pulley and idler pulley in a zig-zag formation.

Step 20. Ensure that the drive belt is properly aligned by rotating the drum by hand. Once the belt is in place, lift the front bulkhead and remount it on the drum. Secure the bulkhead by applying the Philips screws.

Step 21. Lift the control board’s support bracket, then place it against the front bulkhead. Secure the bracket by applying the Philips screws.

Step 22. Plug the drum light and door switch wires back into the main control board. Lift the front panel, then reconnect the door switch wire connector. Mount the panel onto the cabinet, then use your Philips screwdriver to apply the nuts at the top.

Step 23. Open the dryer’s door, then tighten the nuts on the front panel to secure the lint filter housing.

Step 24. Tip the machine backwards carefully and support it. Tighten the Philips screws at the bottom of the panel.

Step 25. Carefully lower the machine back onto the floor. Reconnect the user interface wire connector to the control panel.

Step 26. Snap the control panel onto the front of the cabinet, then apply the nuts at the top using a Philips screwdriver.

Step 27. Place the top cover on the machine, then apply the nuts at the back. Plug your machine into the electrical outlet, then try running a wash cycle to ensure that the issue has been fixed.

AEG Washing Machine Error Code C9 — How To Fix

This AEG washing machine error code indicates that the drive motor has failed. Follow the steps below to replace a damaged motor in your AEG washing machine…

Front Loaders

Do the following to replace a faulty drive motor in your front loader AEG washing machine…

Step 1. Before starting this repair, ensure that you shut the water supply taps and disconnect the power cord from the outlet in order to avoid electrocution and leakage.

Step 2. Go to the back of the cabinet, then use pliers if needed to disconnect the COLD and HOT water inlet hoses (some water may spill, so keep a rag nearby).

Step 3. Loosen the bolts holding the top panel to the machine using a Philips screwdriver. Pull the panel backwards about an inch or so, then lift it off.

Step 4. Take out the screws holding the vibration dampening block to the top of the machine. Lift the block off and set it aside.

Step 5. Use your screwdriver to take out the nut holding the retainer to the drain hose at the back of the machine. Pull the retainer off and set it aside.

Step 6. Unplug the power cord’s grounding wire and wire connector at the back of the cabinet. Use needle-nosed pliers to release the power cord’s wire retainer from the slot on the upper support rail.

See also  GE Washing Machine Not Washing [How To Fix]

Step 7. Using your Philips screwdriver, take out the bolts holding the support rail to the rear access panel. Lift the rail off and set it aside. Loosen the screws holding the rear access panel to the machine.

Step 8. Carefully lift the rear panel off the machine, then support it against the cabinet. Disconnect the wire harness from the drive motor at the bottom of the tub. Carefully unhook the drive belt from the drive pulley and motor pulley.

Step 9. Use a 13mm socket wrench to loosen the nuts securing the drive motor to the bottom of the tub. Carefully lift the drive motor out of the cabinet and set it aside.

Step 10. Prepare your new washing machine drive motor for installation by unpacking it. Mount the new motor at the bottom of the tub, then secure it by applying the nuts.

Step 11. Plug the wire harness into the new drive motor. With the grooved side facing inwards, loop the drive belt around the motor pulley and drive pulley.

Step 12. Carefully rotate the drive pulley to ensure that the belt is properly aligned. Remount the rear access panel on the cabinet, then apply the nuts using your Philips screwdriver.

Step 13. Slide the retainer onto the drain hose, then secure it by tightening the screw. Place the support rail on the rear panel, then apply the Philips screws.

Step 14. Snap the power cord’s wire retainer into the little slot on the support rail. Reconnect the power cord’s grounding wire and wire harness.

Step 15. Mount the vibration block on the cabinet, then apply the screws to secure it. Place the top panel on the machine, then push it forwards. Secure the panel by tightening the Philips screws at the back.

Step 16. Reconnect the COLD and HOT water hoses to the corresponding ports (ensure that each hose is properly attached so water doesn’t spill).

Step 17. Plug your washing machine back into the electrical outlet, then turn the water faucets on. To ensure that the AEG washing machine error code is gone, try running a wash cycle.

Note: Please keep in mind that some of the steps in the section above will be a bit different depending on the model of your washing machine.

Dryers

The steps below show you how to replace a damaged drive motor in your AEG dryer…

Step 1. Unplug your machine from the power outlet before starting this repair in order to prevent electrocution.

Step 2. From the back of the cabinet, loosen the bolts holding the top panel using a Philips screwdriver. Pull the panel backwards, then lift it off.

Step 3. Take out the screws at the top of the control panel. Using a flat-blade screwdriver if needed, pry the control panel off the mounting bracket at the front of the machine.

Step 4. Unplug the user interface wire connector from the control panel, then set the panel aside.

Step 5. Open the door of your dryer, then take out the nuts on the front panel securing the lint filter housing.

Step 6. Tip the appliance backwards a bit and support it (get someone to assist you if needed). Loosen the screws at the bottom of the panel using a Philips screwdriver.

Step 7. Lower the machine back onto the floor. Take out the screws at the top of the front panel. Lift the panel off the machine, then disconnect the door switch wire connector at the back.

Step 8. Set the front panel aside. Unplug the drum light and door switch wire connectors from the main control board.

Step 9. Loosen the screws holding the control board’s support bracket to the front bulkhead. Carefully move the bracket out of place and support it.

Step 10. Take out the nuts holding the front bulkhead to the drum and cabinet. Lift the bulkhead off and set it aside.

Step 11. Reach under the drum and push the idler pulley inwards to release the tension on the drive belt. Slide the belt off the two pulleys.

Step 12. Lift the drum and drive belt out of the cabinet carefully and set them aside. Unplug the wire connector from the drive motor inside the cabinet.

Step 13. Use a pair of pliers to secure the motor’s shaft. Loosen the blower wheel from the housing using a 7/8 inch socket wrench.

Step 14. Pry off the rear and front retaining clamps holding the motor to the cabinet using a flat-blade screwdriver.

Step 15. Carefully pull the motor out of the cabinet and set it aside. Prepare your new drive motor for installation by unpacking it.

Step 16. Install the new motor in the cabinet, then snap the retaining clips on. While securing the motor shaft with pliers, use a 7/8 inch socket wrench to tighten the blower wheel.

Step 17. Plug the wire connector into the new drive motor. Lift the drum and belt, then guide them into the cabinet.

Step 18. From underneath the drum, loop the belt onto the idler and motor pulleys in a zig-zag formation. Ensure that the belt is properly aligned by rotating the drum.

Step 19. Lift the front bulkhead and carefully remount it on the drum. Secure the bulkhead by applying the nuts.

Step 20. Support the control board’s bracket against the bulkhead, then tighten the screws to secure it.

Step 21. Reconnect the door lock and drum light wire connectors to the appropriate terminals on the control board.

Step 22. Lift the front panel, then plug the door switch wire harness in. Snap the front panel onto the cabinet, then use your Philips screwdriver to apply the screws at the top.

Step 23. Open the door, then tighten the screws to secure the housing for the lint filter. Carefully tip the machine backwards and support it. Apply the screws at the bottom of the panel.

Step 24. Lower the machine onto the floor. Plug the user interface wire connector back into the control panel snap the panel onto the front of the cabinet, then apply the screws at the top to secure it.

Step 25. Place the top panel on the machine, then push it forwards. Secure the panel by applying the Philips screws at the back.

Step 26. Plug your dryer into the power outlet. To ensure that the motor works properly, try running a cycle.

AEG Washing Machine Error Code EHO — Quick Fix

The EHO AEG washing machine error code indicates that there is an issue with the power supply. To fix this issue, disconnect your appliance from the power outlet, then plug it back in after 3 minutes.

If the issue persists, there is a problem with your power supply. At this point, it is advised that you contact an electrician to help you.
