Is your Electrolux washing machine beeping? This easy-to-follow guide lists all the causes of this issue, and gives you detailed steps on what to do. So, without wasting any more time, let’s get right to it…
Table of Contents
Electrolux Washing Machine Beeping — Solution
Is your Electrolux washing machine beeping? Here are the issues to look for…
1. Error Code
If your Electrolux washing machine is beeping, it may be as a result of an error code. Check the control panel to see if there’s any message on the screen. To learn how to fix error codes in your Electrolux washing machine, read this article.
2. Machine Is Unbalanced
If your washing machine goes out of balance, it can cause the appliance to keep beeping. Here are the issues to look for if your Electrolux washing machine is going out of balance…
Uneven Legs
Your washing machine will go out of balance if the legs are uneven. Make sure your washing machine stands on a firm, even surface. To help ensure that your machine is balanced, use a spirit level tool.
If you notice that the legs aren’t properly balanced, carefully tip the washing and place a support underneath (get someone to help you hold the machine if needed).
Using channel lock pliers, adjust the legs as needed. Set your washing machine back onto its feet, then use the spirit level tool once more.
Unhooked Suspension Spring
Another thing you should check if your machine is going out of balance is the suspension springs.
Take the top panel off the machine and ensure that both springs are attached to the tub. If one of the springs has come off as a result of improper installation, you’ll need to fix it. Here’s how to do this…
Step 1. In order to prevent electrical damage, ensure that your washing machine is disconnected from the outlet before starting this repair.
Step 2. With a Philips screwdriver, remove the screws holding the top panel to the machine. Slide the top panel backwards, then lift it off the machine.
Step 3. Open your washer’s door, then take the retaining wire off the door boot seal using a pair of needle-nosed pliers or a flat-blade screwdriver.
Step 4. Peel the door gasket off the front panel. With the help of another person, carefully tip your washing machine backwards and place something like a block of wood underneath to support it.
Step 5. Using your Philips screwdriver, loosen the four screws at the bottom of the front panel. Carefully take the support out from underneath the machine, then set the washer upright.
Step 6. Pull the detergent tray out of the housing, then press the button inside to completely release it from the dispenser. Set the tray aside.
Step 7. Use your Philips screwdriver to loosen the two screws next to the detergent drawer housing.
Step 8. With your screwdriver, remove the screws at the front of the panel. Lift the front panel upwards carefully, then take it off the cabinet.
Step 9. To fully release the front panel, disconnect the two electrical connectors. Set the front panel aside.
Step 10. In order to prevent strain, it is advised that you use pair of pliers to release the clamp on the hose attached to the front circulation pump. Pull the hose off the pump.
Step 11. Lift the unhook suspension spring and attach it to the cabinet (get someone to help you support the tub while you do this).
Step 12. In order to prevent the spring from detaching from the cabinet, place the spring retaining strap on the cabinet, then use your Philips screwdriver to apply the screws. Check the other suspension spring to make sure it is properly installed.
Step 13. Reattach the hose to the circulation pump, then slide the retaining clamp into place with a pair of pliers to secure it.
Step 14. Carefully lift the front panel, then plug the two wire connectors to their appropriate terminals.
Step 15. Mount the front panel onto the cabinet. Then use your Philips screwdriver to apply the screws at the top. Apply the two screws next to the detergent drawer housing. Slide the soap tray back in.
Step 16. Get someone to help you tip your washing machine backwards, then place a support underneath the front panel. With your Philips screwdriver, apply the screws at the bottom of the panel.
Step 17. Remove the support from underneath your washing machine, then carefully set it on its feet.
Step 18. Open the door of your washing machine. Fit the door gasket around the front panel. Fit the metal wire around the door boot seal using either your flat-blade screwdriver or needle-nosed pliers.
Step 19. Mount the top panel onto the cabinet, then use your Philips screwdriver to apply the screws at the back.
Step 20. Plug your washing machine’s power cord back into its electrical outlet. To make sure everything works properly, try running a spin cycle.
Faulty Shock Absorber
The shock absorbers are mounted at the bottom of the tub and prevent the assembly from vibrating excessively. If your washing machine is going out of balance, it could be as a result of a damaged shock. Take the following steps to check the shock absorbers in your washing machine…
Checking Rear Shock Absorbers
Check the rear shock absorbers in your Electrolux washing machine with the following steps…
Step 1. Prevent water leaks and electrocution by unplugging your machine from the outlet and turning the water faucets off starting this repair.
Step 2. Spread a cloth on the floor underneath the HOT and COLD water supply hoses. With a pair of pliers, unscrew the water inlet hoses from the ports at the back of the machine (expect some water to spill out).
Step 3. With your Philips screwdriver, loosen the screws securing the top panel to the machine. Slide the top panel backwards about a few inches, then lift it off the machine.
Step 4. Use your screwdriver to take out the screws holding the vibration dampening block to the top of the cabinet. Carefully lift the block off the machine, then set it aside.
Step 5. Take out the nut holding the retainer to the drain hose. Take the retainer off the drain hose and set it aside.
Step 6. Using your Philips screwdriver, remove the nuts holding the rear access panel to the cabinet and motor control board.
Step 7. Loosen the screw holding the power cord grounding wire to the support bracket, then disconnect the power cord electrical connector. Carefully lift the rear panel off the cabinet and set it aside.
Step 8. Inspect the two rear shock absorbers underneath the tub assembly. If you notice any cracks or breaks on either of them, they will need to be replaced. If the shocks feel loose, you’ll also need to replace them.
Step 9. Lift the rear access panel and mount it onto your washer’s cabinet. Using your Philips screwdriver, apply the screws to secure the panel the cabinet and motor control board.
Step 10. Plug the power cord wire connector back in, then apply the screw to secure the grounding wire to the support bracket. Slide the retainer onto the drain hose, then apply the screws to secure it.
Step 11. Place the vibration dampening block on top of the cabinet, then use your Philips screwdriver to apply the screws.
Step 12. Reconnect the two water supply lines to the ports at the back of your washing machine (in order to prevent water leaks, ensure that both hoses are secured properly).
Step 13. Slide the top panel back onto the cabinet, then secure it by applying the screws at the back.
Step 14. Plug the power cord into the electrical outlet, then turn the HOT and COLD water supply faucets back on.
Checking Front Shock Absorbers
Here are the steps you’ll need to take to check for damaged front shock absorbers in your Electrolux washing machine…
Step 1. Before starting this repair, we advise unplugging your washing machine from the power outlet in order to prevent electrocution.
Step 2. Take out the screws at the back of the machine holding the top panel using a Philips screwdriver. Pull the top cover backwards about an inch or so, then lift it off the cabinet.
Step 3. With your Philips screwdriver, take out the screws holding the control panel to the support bracket. Slide the detergent tray out of its housing, then completely release it from the dispenser by pressing the button inside.
Step 4. Remove the two bolts next the detergent drawer housing using your Philips screwdriver. Use a flat-blade screwdriver to pry the control panel off the front of your machine, then disconnect the wire harness.
Step 5. Pry the cap off the main control board mounted on the cabinet (if needed, use a flat-blade screwdriver). Unplug the door lock electrical connector.
Step 6. Open your washing machine’s door, then take out the retaining wire around the door boot seal using either a flat-blade screwdriver or a pair of needle-nosed pliers (take care not to accidentally puncture the door boot seal).
Step 7. Peel the door boot seal off the front of the machine. With the assistance of another person, carefully tip your washing machine backwards, then place a sturdy object underneath the front panel to support it.
Step 8. Use your Philips screwdriver to remove the nuts at the bottom of the front panel. Carefully take the support out from underneath the machine.
Step 9. Loosen the bolts at the top of the front panel using your screwdriver. Carefully pull the front panel upwards, then lift it off the cabinet.
Step 10. Carefully inspect the two shock front shock absorbers at the bottom of the tub. If either shock is cracked or broken, you’ll need to replace them. If you notice that the shock absorbers feel loose, you should also replace them.
Step 11. Lift the main front panel and snap it back onto the cabinet. Use your screwdriver to apply the screws at the top of the front panel.
Step 12. Get someone to help you hold the machine as you tip it backwards. Using your Philips screwdriver, apply the screws at the bottom of the panel. Carefully set your washing machine onto its feet.
Step 13. Open the door of the machine, then fit the door boot seal around the panel. Use a flat-blade screwdriver to help fit the wire around the door gasket.
Step 14. Plug the wire harness back into the terminal on the control panel. Snap the control panel onto the front of the machine, then apply the screws at the top.
Step 15. Apply the two screws beside the detergent dispenser housing, then slide the tray into the housing.
Step 16. Plug the door switch wire connector back into the main control board. Snap the cap onto the control board.
Step 17. Place the top cover on the cabinet, then secure it by applying the bolts at the back with your Philips screwdriver.
To learn how to replace damaged shock absorbers in your Electrolux washing machine, read this guide.
Broken Spider Support Arm
The spider support arm is mounted on the inner tub. The support arm helps the tub spin evenly and smoothly. If your Electrolux washing machine is going out of balance, it could be as a result of a cracked spider arm.
To check if your machine’s spider arm is damaged, open your washer’s door and try rotating the drum by hand. If you hear a creaking noise when spinning the drum, you’ll need to replace the spider support arm. To learn how to replace this part, read this article.
3. Control Board Failure
Another thing that could cause your Electrolux washing machine to keep beeping is a failed user interface control board. Click here to learn how to replace this part in your Electrolux washing machine.
Check out these other articles…
Electrolux Washing Machine Buttons [Issues & Solutions]
How To Balance Electrolux Washer [Detailed Guide]
Electrolux Washing Machine Detergent [Detailed Guide]
Electrolux Washing Machine Stopping [Issues & Solutions]
Electrolux Washing Machine Not Working [Proven Solutions]
How To Turn Off Electrolux Washing Machine Beeping
Follow the steps below to turn off your Electrolux washing machine beeping sound…
Step 1. Plug your washing machine into the electrical outlet, then press the power button to turn it on.
Step 2. Press the button on the control panel to go to the options menu. Use the down arrow button to scroll down to the ‘Settings’ option, then press OK.
Step 3. Scroll down to the ‘Volume’ option then press the OK button. You should now see a number on the display.
Step 4. Using the up or down arrow buttons, change the volume to the desired setting. To stop your machine from beeping, scroll down to ‘0’. Press the OK button once more to save your settings.
