If your Asko washing machine is leaking, this detailed guide will list the possible causes and provide steps to deal with them…
Table of Contents
Asko Washing Machine Is Leaking From The Bottom — How To Fix
If your Asko washing machine is leaking from the bottom, the following are causes to look for…
1. Cracked Pump
If your Asko washing machine is leaking from the bottom, it could be as a result of a cracked pump assembly. Inspect the drain pump in your Asko washing machine by following the steps below…
Step 1. In order to avoid electrocution, disconnect your appliance from the power outlet before starting this repair.
Step 2. Using a Torx screwdriver, take out the bolts at the back of the machine securing the top panel. Pull the panel backwards, then lift it off the cabinet.P
Step 3. Use a flat-blade screwdriver to help release the retaining tabs securing the control panel to the front of the cabinet. Pry the panel off, then set it on top of the machine.
Step 4. Pry the pump filter access panel open (if needed, use a flat-blade screwdriver).
Step 5. Place a small container underneath the emergency drain tube. Pull the cap off the tube, then drain out all the water stuck in the machine.
Step 6. With all the water drained out, push the cap back onto the hose. Get someone to help you tip the appliance backwards and support it.
Step 7. Using your Torx screwdriver, take out the bolts at the bottom of the machine. Set your washing machine back onto its feet.
Step 8. Loosen the bolts at the top of the front panel. Lift the front panel off the cabinet carefully and set it aside.
Step 9. Use a pair of pliers to release the retaining clamps securing the outlet hoses to the pump. Disconnect each hose from the pump (keep a rag nearby in case water spills).
Step 10. Detach the wire harness connected to the pump assembly. Pry the drain pump off the mounts on the cabinet. Take the pump out of the machine.
Step 11. Carefully inspect the pump assembly for cracks and signs of damage. If you notice any damage to the pump, you’ll need to replace it immediately.
Step 12. Once you are sure that the drain pump is in good condition, snap it into place on the cabinet.
Step 13. Plug the wire harness into the pump. Attach each hose to its appropriate port on the pump. Secure the hoses by sliding the retaining clamps into place.
Step 14. Lift the main front panel, then carefully mount it on the cabinet. Secure the front panel by applying the Torx screws at the top.
Step 15. Tip the machine backwards and support it. Use your screwdriver to apply the bolts at the bottom of the front panel.
Step 16. Set your washing machine onto its feet. Snap the control panel onto the front of the cabinet.
Step 17. Ensure that the upper support bracket sits in place. Mount the top panel on the cabinet, then apply the bolts at the back.
Step 18. Plug your washing machine’s power cord into the outlet, then try running a wash cycle to ensure that the leakage has stopped.
2. Loose Hoses
If your Asko washing machine is leaking from the bottom, the second thing to do is check to ensure that the hoses are properly attached. The steps below show you how to do this…
Step 1. In order to prevent any chances of electrocution, it is advised that you disconnect your washing machine from the outlet before starting this repair.
Step 2. Loosen the screws at the back of the machine securing the top panel. Slide the panel backwards about an inch or so, then lift it off the cabinet.
Step 3. Pry the retaining tabs holding the control panel to the front of the machine using a flat-blade screwdriver.
Step 4. Lift the control panel off, then place it on the cabinet. With someone assisting you, carefully tip your machine backwards and place a support underneath it.
Step 5. Use a Torx screwdriver to take out the nuts at the bottom of the front panel. Take the support out from underneath the machine, then lower the appliance.
Step 6. Loosen the bolts at the top of the front panel. Lift the front panel off the cabinet carefully, then set it aside.
Step 7. Inspect the two hoses attached to the drain pump and ensure they are properly connected.
Step 8. If either hose is loose, use pliers to squeeze the retaining clamps and slide them into place.
Step 9. With the hoses properly attached, lift the front panel, then carefully mount it on the cabinet. Tighten the nuts at the top and bottom of the front panel.
Step 10. Snap the control panel back onto the mounting bracket. Mount the top cover on the machine, then use your Torx screwdriver to apply the bolts at the back.
Step 11. Reconnect your washing machine to the electrical outlet. Ensure that the leakage has stopped by running a wash cycle.
Check out these other articles…
KitchenAid Washing Machine Door [6 Issues & Proven Solutions]
KitchenAid Washing Machine Filter [3 Issues & Quick Solutions]
KitchenAid Washing Machine Is Stuck On Rinse [4 Causes & Quick Solutions]
KitchenAid Washing Machine Is Making Noise [8 Causes & Proven Solutions]
Asko Washing Machine Will Not Drain [2 Causes & Quick Solutions]
Asko Washing Machine Is Not Filling With Water [6 Problems & Proven Solutions]
Zanussi Washing Machine Is Not Draining [2 Problems & Quick Solutions]
3. Damaged Sump Hose
If your Asko washing machine is leaking from the bottom, the next probable cause is a punctured sump hose. The steps below show you how to replace this part…
Step 1. In order to avoid any chances of electrocution, it is advised that you disconnect your appliance from the power outlet before starting this repair.
Step 2. Take out the bolts at the back of the machine securing the top panel, using a Torx-20 screwdriver. Lift the top cover off the machine and set it aside.
Step 3. With a flat-blade screwdriver, release the retaining clips securing the control panel to the front of the machine. Lift the panel off, then place it on the cabinet.
Step 4. With someone assisting you, tip your washing machine backwards a bit and support it. Using a Torx screwdriver, take out the nuts at the bottom of the front panel.
Step 5. Lower the machine onto its feet, then take out the bolts at the top of the panel. Lift the front panel off the cabinet carefully, then set it aside.
Step 6. Place a small dish underneath the emergency drain tube. Pull the cap off the tube, then let any water stuck in the machine drain out.
Step 7. With all the water drained out, push the cap back into the hose. Use a pair of pliers to release the retaining clamp securing the sump hose to the bottom of the tub.
Step 8. Detach the sump hose from the bottom of the machine (some water may spill).
Step 9. Release the retaining clamp securing the other end of the sump hose to the drain pump. Detach the hose from the pump.
Step 10. Using a flat-blade screwdriver if needed, detach the pressure tube from the air chamber. Pull the sump hose assembly out of the cabinet, then set it aside.
Step 11. Prepare the new sump hose for installation by unpacking it. Transfer the retaining clamps from the old hose to the new one.
Step 12. Connect the pressure tube to the port on the new pressure chamber. Connect one end of the new sump hose to the port at the bottom of the tub. Secure the connection by snapping the retaining clamp into place.
Step 13. Attach the other end of the hose to the port on the pump, then secure it using the retaining clamp.
Step 14. Lift the front panel, then carefully mount it on the cabinet. Using your Torx screwdriver, apply the bolts at the top of the front panel.
Step 15. Tip the machine backwards carefully and support it. Apply the bolts at the bottom of the front panel.
Step 16. Lower the machine back onto the floor. Snap the control panel onto the front of the cabinet.
Step 17. Mount the top cover on the cabinet, then use your screwdriver to apply the bolts at the back.
Step 18. Connect your washing machine to the power outlet, then try running a cycle to ensure that the leakage has stopped.
Asko Washing Machine Is Leaking — Quick Fix
If your Asko washing machine is leaking, look for the following issues…
1. Inlet Hose Is Loose
If your Asko washing machine is leaking, the first thing you should do is check to ensure that the hose is properly attached. Go to the back of the machine, then use pliers to tighten the hose’s connection to the inlet port.
2. Damaged Inlet Hose
If your Asko washing machine is leaking, another thing you’ll need to inspect is the inlet hose.
Turn the power supply and water tap off in order to prevent leakage and electrocution. Using a pair of pliers if needed, disconnect the water supply hose from the port at the back of the machine.
Place the end of the hose in a bucket, then turn the water tap on partially. While the water is running, carefully run your hand over the hose and inspect it for leaks. If you notice any damage to the hose, you’ll need to replace it immediately.
Once you are sure that the hose is in good condition, turn the water tap off. Reconnect the hose to the port at the back of the machine.
Turn the water supply tap back on, then plug the power cord into the outlet. Ensure that the leakage has stopped by running a wash cycle.
3. Water Inlet Valve Is Cracked
If your washer’s inlet valve is damaged, water may leak out from it during wash cycles. Follow the steps below to inspect your washer’s inlet valve…
Step 1. Turn the water supply taps off and disconnect your appliance from the power outlet before starting this procedure, in order to prevent leakage and electrocution.
Step 2. Detach the water supply hose from the port at the back of the machine (keep a rag nearby to clean any leaks).
Step 3. Using a Torx-20 screwdriver, loosen the bolts at the back of the cabinet securing the top panel. Lift the panel off the cabinet.
Step 4. Note the positioning of the wires attached to the inlet valve, then disconnect each one.
Step 5. Use pliers to release the retaining clamps securing the outlet tubes to the valve. Detach the tubes from the valve assembly.
Step 6. Use your Torx screwdriver to take out the nuts securing the valve to the cabinet. Pull the valve out of the machine.
Step 7. Carefully inspect the inlet valve for cracks or any signs of damage. If the valve is damaged in any way, you’ll need to replace it.
Step 8. Once you’ve gotten the new inlet valve, or you’re sure that your valve is in good condition, remount it on the cabinet, then apply the bolts.
Step 9. Reconnect the outlet tubes to the ports on the valve assembly. Secure the hoses by sliding the spring clamps into place.
Step 10. Plug the wire harnesses into the appropriate terminals on the inlet vale. Reconnect the outlet hose to the valve port at the back of the machine (ensure that the hose is properly attached in order to prevent leaks).
Step 11. Remount the top panel on the cabinet, then use your Torx-20 screwdriver to apply the bolts at the back.
Step 12. Reconnect your washing machine to the power outlet, then turn the water supply taps on. To ensure that the leakage has stopped, try running a wash cycle.
4. Damaged Door Seal.
Your washing machine may start to leak from the door if the door gasket is damaged. To replace this part, follow the steps below…
Step 1. Disconnect your washing machine from the power outlet before starting this repair, in order to prevent any chances of electrocution.
Step 2. Open the door of your machine. Using a small flat-blade screwdriver, carefully release the tabs securing the outer door frame to the assembly.
Step 3. Using a Torx-20 screwdriver, loosen the bolts securing the lower and upper retaining tabs to the door assembly.
Step 4. Loosen the bolt securing the door strike using your Torx screwdriver. Take out the remaining bolts on the door frame, then pull the glass out of place.
Step 5. Pry the rubber seal off the door frame, then discard it. Prepare the new door seal for installation by unpacking it.
Step 6. Carefully fit the new door seal around the door frame. Remount the door glass on the frame.
Step 7. Put the door strike and retaining clips on the frame, then use your Torx screwdriver to apply all the bolts.
Step 8. Snap the outer frame onto the door assembly. Close the door on the machine, then reconnect the appliance to the outlet. Ensure that the leakage has stopped by running a wash cycle.
5. Damaged/Loose Dispenser Hoses
If your Asko washing machine is leaking, it could be that the dispenser hoses are damaged or loose. Follow the steps below to fix this issue…
Step 1. In order to prevent leakage and electrocution, disconnect your appliance from the outlet and turn the water supply taps off before starting this repair.
Step 2. Take out the bolts at the back of the machine securing the top panel. Slide the panel backwards and lift it off the cabinet.
Step 3. Carefully inspect the hoses going from the inlet valve to the dispenser. If you notice any damage to the hoses, you’ll need to release the retaining clamps and replace the hoses.
Step 4. If you notice that the inlet valve outlet hoses are loose, use pliers to squeeze the retaining clamps and slide them out of place.
Step 5. Properly connect the hoses to the valve, then move the retaining clamps into place.
Step 6. Mount the top panel on the cabinet, then use your Torx screwdriver to tighten the screws at the back.
Step 7. Turn your washing machine’s water tap back on, then plug the power cord into the outlet. Ensure that the leakage has stopped by running a wash cycle.
6. Damaged Drain Hose
If your Asko washing machine is leaking, it could be due to a damaged drain hose. Follow the steps below to replace this part…
Step 1. Disconnect your appliance from the power outlet before starting this procedure, in order to avoid electrocution.
Step 2. Go to the front of the machine, then pry the pump filter access pane open (if needed, use a flat-blade screwdriver).
Step 3. Place a small container under the emergency drain tube. Pull the cap off the hose, then let all the water in the machine drain out.
Step 4. With all the water drained out, push the cap back onto the hose. Go to the back of the machine, then pry the hose retainer open.
Step 5. Pull the drain hose out of the retainer. Using your Torx-20 screwdriver, take out the bolts holding the rear access panel. Lift the rear panel off the cabinet and set it aside.
Step 6. Loosen the bolts at the back of the cabinet securing the top panel. Pull the panel backwards, then lift it off the cabinet.
Step 7. From the back of the machine, reach into the cabinet, then release the retaining clamp securing the drain hose to the pump.
Step 8. Detach the drain hose from the pump (some water may spill). Use a flat-blade screwdriver to pry the drain hose retaining clips off the cabinet.
Step 9. Pry the retaining bracket off the drain hose. Pull your washer’s drain hose out of the standpipe, then detach the goose-neck retaining bracket from it.
Step 10. Pull the drain hose out of the cabinet, then discard it. Prepare the new hose assembly for installation by taking it out of its packaging.
Step 11. Insert the straight end of the new hose through the opening on the cabinet. Connect one end of the drain hose to the pump, then secure it with the retaining clamp.
Step 12. Snap the retaining bracket onto the drain hose. Snap the retaining clips on the hose onto the cabinet.
Step 13. Carefully mount the top panel on the cabinet, then use your Torx screwdriver to apply the bolts at the back.
Step 14. Remount the rear access panel onto the cabinet, then secure it by tightening the Torx screws.
Step 15. Secure the drain hose and water inlet hose in the retaining bracket at the back of the machine.
Step 16. Snap the goose-neck retainer onto the new drain hose. Insert the new drain hose into the home drain.
Step 17. Reconnect your appliance to the power outlet, then try running a wash cycle to ensure that the leakage has stopped.
